Performance Data
Model: FCQN125EXV1- RQ125DXY1
Cooling Mode
AFR
(CFM)
EWB EDB
Outdoor temperature
19°C 25°C 30°C 35°C 40°C 46°C
TC SC PI TC SC PI TC SC PI TC SC PI TC SC PI TC SC PI
930
16°C
21°C 11.88 8.18 3.34 11.46 7.97 3.61 11.03 7.75 3.91 10.59 7.53 4.24 9.73 7.01 4.60 8.98 6.59 5.07
24°C 11.90 9.80 3.34 11.47 9.57 3.61 11.05 9.35 3.91 10.61 9.12 4.24 9.75 8.52 4.60 9.01 8.04 5.07
27°C 11.99 11.11 3.34 11.59 10.86 3.61 11.18 10.60 3.92 10.76 10.33 4.25 9.93 9.61 4.61 9.24 9.03 5.09
30°C 12.36 12.36 3.36 12.00 12.00 3.64 11.64 11.64 3.94 11.27 11.27 4.28 10.44 10.44 4.65 9.77 9.77 5.14
19°C
24°C 13.11 7.64 3.39 12.65 7.45 3.67 12.18 7.25 3.97 11.70 7.04 4.31 10.75 6.56 4.68 9.94 6.18 5.15
27°C 13.11 8.74 3.39 12.65 8.54 3.67 12.19 8.35 3.98 11.71 8.15 4.31 10.76 7.62 4.68 9.95 7.22 5.16
30°C 13.13 10.79 3.39 12.68 10.56 3.67 12.23 10.32 3.98 11.77 10.07 4.32 10.84 9.42 4.68 10.05 8.92 5.16
33°C 13.29 13.29 3.40 12.86 12.86 3.68 12.44 12.44 3.99 12.02 12.02 4.33 11.12 11.12 4.71 10.39 10.39 5.20
22°C
27°C 14.42 7.48 3.45 13.92 7.30 3.74 13.41 7.11 4.05 12.89 6.92 4.39 11.85 6.45 4.77 10.97 6.08 5.25
30°C 14.42 9.11 3.45 13.92 8.92 3.74 13.41 8.72 4.05 12.89 8.51 4.40 11.85 7.96 4.77 10.97 7.55 5.25
33°C 14.43 10.64 3.45 13.93 10.44 3.74 13.42 10.23 4.05 12.90 10.02 4.40 11.87 9.41 4.77 11.00 8.94 5.26
36°C 14.48 12.07 3.45 14.00 11.83 3.74 13.51 11.58 4.06 13.02 11.32 4.40 12.01 10.62 4.78 11.16 10.07 5.27
1030
16°C
21°C 12.36 8.53 3.37 11.91 8.31 3.64 11.46 8.09 3.94 10.99 7.86 4.27 10.09 7.32 4.63 9.31 6.89 5.11
24°C 12.40 10.36 3.37 11.95 10.11 3.64 11.51 9.87 3.95 11.04 9.62 4.28 10.14 8.98 4.64 9.38 8.47 5.11
27°C 12.55 11.76 3.38 12.13 11.49 3.65 11.71 11.19 3.96 11.29 10.86 4.29 10.42 10.09 4.66 9.71 9.44 5.14
30°C 13.07 13.07 3.40 12.69 12.69 3.68 12.31 12.31 3.99 11.91 11.91 4.33 11.03 11.03 4.71 10.31 10.31 5.20
19°C
24°C 13.62 8.07 3.42 13.13 7.87 3.70 12.64 7.66 4.01 12.13 7.45 4.35 11.14 6.95 4.72 10.29 6.55 5.20
27°C 13.64 9.30 3.42 13.15 9.09 3.70 12.66 8.89 4.01 12.15 8.68 4.35 11.17 8.11 4.72 10.32 7.68 5.20
30°C 13.71 11.47 3.43 13.23 11.22 3.71 12.76 10.97 4.02 12.27 10.70 4.36 11.30 10.01 4.73 10.48 9.45 5.22
33°C 13.94 13.94 3.44 13.51 13.51 3.72 13.08 13.08 4.04 12.65 12.65 4.39 11.71 11.71 4.77 10.95 10.95 5.26
22°C
27°C 14.96 7.90 3.48 14.44 7.72 3.77 13.90 7.52 4.09 13.35 7.32 4.44 12.26 6.83 4.81 11.34 6.44 5.30
30°C 14.98 9.70 3.48 14.45 9.50 3.77 13.91 9.29 4.09 13.36 9.07 4.44 12.28 8.49 4.81 11.36 8.06 5.30
33°C 15.01 11.36 3.49 14.49 11.15 3.78 13.95 10.92 4.10 13.41 10.69 4.44 12.33 10.02 4.82 11.43 9.52 5.31
36°C 15.10 12.85 3.49 14.61 12.60 3.79 14.10 12.34 4.10 13.59 12.05 4.45 12.54 11.28 4.83 11.69 10.64 5.33
1200
16°C
21°C 12.82 8.90 3.39 12.35 8.68 3.67 11.87 8.45 3.97 11.38 8.21 4.31 10.44 7.65 4.67 9.62 7.20 5.15
24°C 12.89 10.82 3.40 12.42 10.56 3.67 11.95 10.30 3.98 11.47 10.03 4.31 10.53 9.36 4.68 9.73 8.83 5.16
27°C 13.09 12.40 3.41 12.67 12.08 3.69 12.24 11.74 4.00 11.80 11.38 4.34 10.90 10.54 4.71 10.16 9.84 5.20
30°C 13.75 13.75 3.44 13.35 13.35 3.72 12.94 12.94 4.04 12.51 12.51 4.38 11.58 11.58 4.76 10.82 10.82 5.26
19°C
24°C 14.11 8.54 3.45 13.60 8.33 3.73 13.08 8.12 4.04 12.55 7.90 4.39 11.52 7.36 4.76 10.63 6.94 5.24
27°C 14.15 9.88 3.45 13.64 9.65 3.74 13.13 9.43 4.05 12.60 9.20 4.39 11.57 8.60 4.76 10.69 8.14 5.25
30°C 14.27 12.16 3.46 13.76 11.89 3.74 13.27 11.62 4.06 12.76 11.33 4.40 11.75 10.58 4.77 10.91 9.98 5.26
33°C 14.58 14.58 3.47 14.15 14.15 3.77 13.71 13.71 4.09 13.26 13.26 4.44 12.29 12.29 4.82 11.49 11.49 5.32
22°C
27°C 15.48 8.35 3.51 14.93 8.17 3.81 14.37 7.97 4.13 13.79 7.76 4.47 12.67 7.24 4.85 11.71 6.84 5.34
30°C 15.51 10.30 3.52 14.96 10.10 3.81 14.40 9.88 4.13 13.82 9.66 4.48 12.70 9.05 4.85 11.74 8.58 5.35
33°C 15.57 12.07 3.52 15.03 11.86 3.81 14.48 11.61 4.13 13.91 11.35 4.48 12.80 10.64 4.86 11.85 10.10 5.36
36°C 15.71 13.63 3.53 15.21 13.38 3.82 14.69 13.09 4.15 14.16 12.76 4.50 13.08 11.90 4.89 12.20 11.21 5.39
Model: FCQN125EXV1- RQ125DXY1
Heating Mode
ID DB
Outdoor WB
-9°C -6°C -5°C 6°C 12°C 15°C 18°C
TC SC TC SC TC SC TC SC TC SC TC SC TC SC
15°C
8.209 8.209 9.291 9.291 9.651 9.651 13.619 13.619 15.783 15.783 16.865 16.865 17.947 17.947
17°C
7.993 7.993 9.403 9.403 9.434 9.434 13.603 13.603 15.559 15.559 16.639 16.639 17.720 17.720
19°C
7.778 7.778 9.515 9.515 9.217 9.217 13.587 13.587 15.334 15.334 16.414 16.414 17.493 17.493
21°C
7.563 7.563 9.345 9.345 9.000 9.000 13.394 13.394 15.110 15.110 16.188 16.188 17.266 17.266
23°C
7.348 7.348 8.894 8.894 8.783 8.783 13.025 13.025 14.885 14.885 15.962 15.962 17.039 17.039
25°C
7.133 7.133 8.443 8.443 8.566 8.566 12.657 12.657 14.661 14.661 15.736 15.736 16.811 16.811
27°C
6.917 6.917 7.991 7.991 8.350 8.350 12.288 12.288 14.436 14.436 15.510 15.510 16.584 16.584
Frost Region
Remark:
AFR: Air fl ow rate (CFM)
EWB: Entering Wet Bulb Temp. (°C)
EDB: Entering Dry Bulb Temp. (°C)
TC: Total Cooling / Heating Capacity (kW)
SC: Sensible Cooling / Heating Capacity (kW)
PI: Power Input (kW)
Notes:
1. Ratings shown are net capacities.
2. shows nominal capacities.
3. Direct interpolation is permissible. Do not extrapolate.
4. Unit is able to operate at ambient from 19°C to 46°C DB (cooling) / -9°C to 18°C WB (heating) without pressure trip.
