Engineering & Physical Data
Engineering & Physical Data
Engineering Data - R410A model
MODEL
INDOOR UNIT FFRN25CXV1 FFRN35CXV1 FFRN50CXV1
OUTDOOR UNIT RN25CXV1 RN35CXV1 RN50CXV1
NOMINAL COOLING CAPACITY
Btu/h 9500 12500 17500
W 2780 3660 5129
NOMINAL TOTAL INPUT POWER (COOLING) W 900 1300 1690
NOMINAL RUNNING CURRENT (COOLING) A 4 5.90 7.72
EER W/W 3.09 2.82 3.03
REFRIGERANT CONTROL (EXPANSION DEVICE) OUTDOOR CAPILLARY TUBE
REFRIGERANT CHARGE kg 0.73 0.83 1.38
MODEL
INDOOR UNIT FFQN25CXV1 FFQN35CXV1 FFQN50CXV1
OUTDOOR UNIT RYN25CXV1 RYN35CXV1 RYN50CXV1
NOMINAL COOLING CAPACITY
Btu/h 9500 12500 17500 18000
W 2780 3660 5129 5280
NOMINAL HEATING CAPACITY
Btu/h 9500 11500 17500 18000
W 2780 3370 5129 5420
NOMINAL TOTAL INPUT POWER (COOLING) W 900 1300 1690 1724
NOMINAL TOTAL INPUT POWER (HEATING) W 830 1020 1710 1494
NOMINAL RUNNING CURRENT (COOLING) A 4 5.9 7.72 3.3
NOMINAL RUNNING CURRENT (HEATING) A 3.7 4.60 7.75 2.80
EER W/W 3.09 2.82 3.03 3.06
COP W/W 3.35 3.30 3.00 3.63
REFRIGERANT CONTROL (EXPANSION DEVICE) OUTDOOR CAPILLARY TUBE
REFRIGERANT CHARGE kg 0.73 0.83 1.38 1.38
POWER SOURCE V/Ph/Hz 220 - 240 /1/50
REFRIGERANT TYPE R410A
INDOOR UNIT
CONTROL
AIR DISCHARGE 4 WAY AUTOMATIC LOUVER (UP & DOWN)
OPERATION WIRELESS MICROCOMPUTER REMOTE CONTROL
AIR FLOW
HIGH l/s / CFM 194 / 410 194 / 410 212 / 450 212 / 450
MEDIUM l/s / CFM 170 / 360 170 / 360 194 / 410 194 / 410
LOW l/s / CFM 156 / 330 156 / 330 160 / 340 160 / 340
SOUND PRESSURE LEVEL (H/M/L) dBA 41 / 38 / 35 41 / 38 / 34 44 / 41 / 37 44 / 41 / 37
UNIT DIMENSION [Panel] HEIGHT X WIDTH X DEPTH mm 250X 570 X 570 [295 x 640 x 640]
PACKING DIMENSION HEIGHT X WIDTH X DEPTH mm 317 X 630 X 630
UNIT WEIGHT (UNIT + PANEL) kg 22 + 2 23 + 2 23 + 2 23 + 2
CONDENSATE DRAIN SIZE mm 19.05
FAN
TYPE TURBO
DRIVE DIRECT
FAN MOTOR
TYPE INDUCTION
INDEX OF PROTECTION (IP) IP20
INSULATION GRADE CLASS B
RATED INPUT POWER W 55 65 59 59
RATED RUNNING CURRENT A 0.24 0.29 0.25 0.25
MOTOR MAX OUTPUT W 19 23 28 28
POLES 6
COIL
TUBE
MATERIAL SEAMLESS INNER GROOVE COPPER
DIAMETER mm 7
FIN
MATERIAL ALUMINIUM (SLIT FIN)
FACE AREA m
2
0.318
ROW 12
AIR QUALITY FILTER
TYPE WASHABLE SARANET FILTER
QUANTITY pc 1
CASING COLOUR WITHOUT PAINT
AIR FLOW I/s / CFM 396 / 840 453 / 960 614 / 1300 614 / 1300
OUTDOOR UNIT
SOUND PRESSURE LEVEL dBA 46 49 52 52
UNIT DIMENSION HEIGHT X WIDTH X DEPTH mm 540 X 700 X 250 540 X 700 X 250 651 X 855 X 328 651 X 855 X 328
PACKING DIMENSION HEIGHT X WIDTH X DEPTH mm 620 X 810 X 330 620 X 810 X 330 710 X 990 X 415 710 X 990 X 415
UNIT WEIGHT (RN / RYN) kg 28 30 47 47
PIPE
CONNECTION
TYPE FLARE VALVE
SIZE
LIQUID mm 6.35 6.35 6.35 6.35
GAS mm 9.52 12.70 12.70 12.70
FAN
TYPE PROPELLER
DRIVE DIRECT
FAN MOTOR
TYPE INDUCTION
INDEX OF PROTECTION (IP) IP22 IP22 IP23 IP23
INSULATION GRADE CLASS B CLASS B CLASS F CLASS F
RATED INPUT POWER W 57 70 80 80
RATED RUNNING CURRENT A 0.25 0.31 0.36 0.36
MOTOR OUTPUT W 24 35 42 42
POLES 6666
COMPRESSOR
TYPE ROTARY
OIL TYPE RB68A or FREOL ALPHA68M RB68A or FREOL ALPHA68M
OIL AMOUNT cm
3
350 430 670 670
RN RATED INPUT POWER W 788 1165 1551 1693
RYN
RATED INPUT POWER
(COOLING)
W 788 1165 1551 1693
RATED INPUT POWER
(HEATING)
W 718 881 1571 1643
RATED RUNNING CURRENT A 3.51 5.3 7.11 7.49
RATED RUNNING CURRENT
(COOLING)
A 3.51 5.3 7.11 7.49
RATED RUNNING CURRENT
(HEATING)
A 3.21 3.98 7.14 7.29
LOCKED ROTOR AMP. A 19 24 26 26
COIL
TUBE
MATERIAL SEAMLESS INNER GROOVE COPPER
DIAMETER (RN/RYN) mm 7 7 / 9.52 7 7
FIN
MATERIAL ALUMINIUM (RAISE LANCE)
FACE AREA m
2
0.36 0.51
ROW 1122
CASING COLOUR LIGHT GREY
ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151 (NON-DUCTED UNIT) OR ISO 13253 (DUCTED UNIT).
COOLING HEATING
INDOOR: 27°C DB/ 19°C WB INDOOR: 20°C DB
OUTDOOR: 35°C DB/ 24°C WB OUTDOOR: 7°C DB/ 6°C WB
