22
Engineering & Physical Data
Engineering Data - R410A MODEL
MODEL
INDOOR UNIT FCRN50EXV1 FCRN60EXV1 FCRN71EXV1 FCRN100EXV1
OUTDOOR UNIT RN50CXV1 RN60CXV1 RR71CXV1 RR90DXV1
NOMINAL COOLING CAPACITY
Btu/h 18300 22200 27000 29200
W 5363 6506 7913 8558
NOMINAL TOTAL INPUT POWER (COOLING) W 1740 1940 2790 2820
NOMINAL RUNNING CURRENT (COOLING) A 7.72 8.67 13.10 13.70
EER W/W 3.08 3.36 2.84 3.03
REFRIGERANT CONTROL (EXPANSION DEVICE) OUTDOOR CAPILLARY TUBE
REFRIGERANT CHARGE kg 1.38 1.54 2.03 2.60
MODEL
INDOOR UNIT FCQN50EXV1 FCQN60EXV1 FCQN71EXV1 FCQN100EXV1
OUTDOOR UNIT RYN50CXV1 RYN60CXV1 RQ71CXV1 RQ90DXV1
NOMINAL COOLING CAPACITY
Btu/h 18300 22200 27000 29200
W 5363 6506 7913 8558
NOMINAL HEATING CAPACITY
Btu/h 17700 20500 28000 31800
W 5188 6008 8206 9320
NOMINAL TOTAL INPUT POWER (COOLING) W 1740 1940 2790 2820
NOMINAL TOTAL INPUT POWER (HEATING) W 1490 1760 2325 2545
NOMINAL RUNNING CURRENT (COOLING) A 7.72 8.67 13.08 13.7
NOMINAL RUNNING CURRENT (HEATING) A 6.61 7.86 11.20 12.80
EER W/W 3.08 3.36 2.84 3.03
COP W/W 3.48 3.41 3.53 3.66
REFRIGERANT CONTROL (EXPANSION DEVICE) OUTDOOR CAPILLARY TUBE
REFRIGERANT CHARGE kg 1.38 1.54 2.03 2.60
POWER SOURCE V/Ph/Hz 220 - 240 /1/50
REFRIGERANT TYPE R410A
INDOOR UNIT
CONTROL
AIR DISCHARGE 4 WAY AUTOMATIC LOUVER (UP & DOWN)
OPERATION WIRELESS MICROCOMPUTER REMOTE CONTROL
AIR FLOW
HIGH l/s / CFM 280 / 600 320 / 680 410 / 860 490 / 1030
MEDIUM l/s / CFM 250 / 530 280 / 600 340 / 725 410 / 860
LOW l/s / CFM 200 / 430 250 / 530 290 / 620 350 / 740
SUPER LOW l/s / CFM 190 / 400 200 / 430 250 / 530 295 / 620
SOUND PRESSURE LEVEL (H/M/L/SL) dBA 34 / 32 / 30 / 28 37 / 34 / 33 / 32 42 / 38 / 35 / 33 47 / 44 / 40 / 36
UNIT DIMENSION [Panel] HEIGHT X WIDTH X DEPTH mm 265 X 820 X 820 [340 X 990 X 990]
300 X 820 X 820
[375 X 990 X 990]
PACKING DIMENSION HEIGHT X WIDTH X DEPTH mm 300 X 916 X 916 335 X 916 X 916
UNIT WEIGHT (UNIT + PANEL) kg 29 + 6 42 + 6
CONDENSATE DRAIN SIZE mm 19.05
FAN
TYPE BLOWER WHEEL
DRIVE DIRECT
FAN MOTOR
TYPE INDUCTION
INDEX OF PROTECTION (IP) IP20
INSULATION GRADE CLASS B
RATED INPUT POWER W 88 101 145 176
RATED RUNNING CURRENT A 0.39 0.44 0.64 0.79
MOTOR MAX OUTPUT W 20 30 50 60
POLES 6
COIL
TUBE
MATERIAL SEAMLESS INNER GROOVE COPPER
DIAMETER mm 7
FIN
MATERIAL ALUMINIUM (SLIT FIN)
FACE AREA m
2
0.386 0.372 0.461
ROW 23
AIR QUALITY FILTER
TYPE WASHABLE SARANET FILTER
QUANTITY pc 1
CASING COLOUR WITHOUT PAINT
AIR FLOW I/s / CFM 614 / 1300 689 / 1460 684 / 1450 1605 / 3400
OUTDOOR UNIT
SOUND PRESSURE LEVEL dBA 52 52 58 58
UNIT DIMENSION HEIGHT X WIDTH X DEPTH mm 651 X 855 X 328 753 X 855 X 328 852 X 1030 X 400
PACKING DIMENSION HEIGHT X WIDTH X DEPTH mm 710 X 990 X 415 810 X 990 X 415 1010 X 1180 X 514
UNIT WEIGHT (RN / RYN) kg 47 50 57 86
PIPE
CONNECTION
TYPE FLARE VALVE
SIZE
LIQUID mm 6.35 9.52
GAS mm 12.70 15.88 15.88 15.88
FAN
TYPE PROPELLER
DRIVE DIRECT
FAN MOTOR
TYPE INDUCTION
INDEX OF PROTECTION (IP) IP23 IP23 N / A
INSULATION GRADE CLASS F CLASS F CLASS F CLASS B
RATED INPUT POWER W 80 97 124 257
RATED RUNNING CURRENT A 0.36 0.43 0.54 1.10
MOTOR OUTPUT W 42 64 75 145
POLES 68
COMPRESS
OR
TYPE ROTARY ROTARY SCROLL
OIL TYPE RB68A or Freol Alpha68M
RB68A or Freol
Alpha68M
MOBIL EAL ARCTIC
22C
OIL AMOUNT cm
3
670 1130 1242
RN RATED INPUT POWER W 1572 1742 2521 2387
RYN
RATED INPUT POWER
(COOLING)
W 1572 1742 2521 2387
RATED INPUT POWER
(HEATING)
W 1322 1562 2056 2112
RATED RUNNING CURRENT A 6.97 7.8 11.9 11.8
RATED RUNNING CURRENT
(COOLING)
A 6.97 7.8 11.9 11.8
RATED RUNNING CURRENT
(HEATING)
A 5.86 6.99 10.00 10.90
LOCKED ROTOR AMP. A 26 63 65 97
COIL
TUBE
MATERIAL SEAMLESS INNER GROOVE COPPER
DIAMETER (RN/RYN) mm 7
FIN
MATERIAL ALUMINIUM(RAISE LANCE) ALUMINIUM (CORR. FIN)
FACE AREA m
2
0.51 0.62 0.62 0.87
ROW 2
CASING COLOUR LIGHT GREY
ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151 (NON-DUCTED UNIT) OR ISO 13253 (DUCTED UNIT).
COOLING HEATING
INDOOR: 27°C DB/ 19°C WB INDOOR: 20°C DB
OUTDOOR: 35°C DB/ 24°C WB OUTDOOR: 7°C DB/ 6°C WB
