Engineering & Physical Data
Engineering Data - R22 MODEL
MODEL
INDOOR UNIT FDM25CXV1 FDM28CXV1 FDM28CXV1
OUTDOOR UNIT R25CXV1 R28CXV1 R30DXV1
NOMINAL COOLING CAPACITY
Btu/h 23500 27000 28000
W 6890 7913 8206
NOMINAL TOTAL INPUT POWER (COOLING) W 2616 3091 2821
NOMINAL RUNNING CURRENT (COOLING) A 11.70 15.10 12.92
EER W/W 2.69 2.64 3.01
REFRIGERANT CONTROL (EXPANSION DEVICE) OUTDOOR CAP.TUBE INDOOR CAP. TUBE INDOOR CAP. TUBE
REFRIGERANT CHARGE kg 1.50 1.75 1.60
MODEL
INDOOR UNIT FDYM25CXV1 FDYM28CXV1 FDYM28CXV1 FDYM28CXV1
OUTDOOR UNIT RY25CXV1 RY28CXV1 RY30DXV1 RY30DXY1
NOMINAL COOLING CAPACITY
Btu/h 23500 27000 30000 30000
W 6890 7913 8792 8792
NOMINAL HEATING CAPACITY
Btu/h 24000 28000 30000 30000
W 7030 8206 8792 8792
NOMINAL TOTAL INPUT POWER (COOLING) W 2616 3091 3090 3070
NOMINAL TOTAL INPUT POWER (HEATING) W 2536 2638 3060 3040
NOMINAL RUNNING CURRENT (COOLING) A 11.70 15.10 14.70 5.10
NOMINAL RUNNING CURRENT (HEATING) A 11.50 13.40 14.60 5.00
EER W/W 2.69 2.64 2.94 2.96
COP W/W 2.83 3.23 2.97 2.99
REFRIGERANT CONTROL (EXPANSION DEVICE) OUTDOOR CAP. TUBE OUTDOOR CAP. TUBE
OUTDOOR CAP. TUBE
+ TXV
OUTDOOR CAP. TUBE
+ TXV
REFRIGERANT CHARGE kg 1.50 1.83 2.15 2.15
POWER SOURCE V/Ph/Hz 220 - 240 / 1 / 50 220 - 240 / 1 / 50 220 - 240 / 1 / 50 380 - 415 / 3 / 50
REFRIGERANT TYPE R22 R22 R22 R22
INDOOR UNIT
CONTROL
AIR DISCHARGE DUCTED DUCTED DUCTED DUCTED
OPERATION SLM WIRED HANDSET SLM WIRED HANDSET SLM WIRED HANDSET SLM WIRED HANDSET
AIR FLOW
SUPER HIGH l/s / CFM - 401 / 850 401 / 850 401 / 850
HIGH l/s / CFM 345 / 730 382 / 810 382 / 810 382 / 810
MEDIUM l/s / CFM 311 / 660 363 / 770 363 / 770 363 / 770
LOW l/s / CFM 274 / 580 335 / 710 335 / 710 335 / 710
EXTERNAL STATIC PRESSURE (H/M/L) Pa (in.wg.)
49 / 43 / 30
(0.2 / 0.17 / 0.12)
98 / 78 / 68 / 59
(0.4 / 0.3 / 0.3 / 0.2)
98 / 78 / 68 / 59
(0.4 / 0.3 / 0.3 / 0.2)
98 / 78 / 68 / 59
(0.4 / 0.3 / 0.3 / 0.2)
SOUND PRESSURE LEVEL (H/M/L) dBA 41 / 40 / 36 44 / 41 / 38 / 34 44 / 41 / 38 / 34 44 / 41 / 38 / 34
UNIT DIMENSION HEIGHT X WIDTH X DEPTH mm 261 x 1200 x 411 285 x 932 x 600 285 x 932 x 600 285 x 932 x 600
PACKING DIMENSION HEIGHT X WIDTH X DEPTH mm 376 x 1386 x 541 343 x 1138 x 690 343 x 1138 x 690 343 x 1138 x 690
UNIT WEIGHT kg 25 38 38 38
CONDENSATE DRAIN SIZE mm 19.1 19.1 19.1 19.1
FAN
TYPE CENTRIFUGAL CENTRIFUGAL CENTRIFUGAL CENTRIFUGAL
DRIVE DIRECT DIRECT DIRECT DIRECT
FAN MOTOR
TYPE INDUCTION INDUCTION INDUCTION INDUCTION
INDEX OF PROTECTION (IP) IP20 IP21 IP21 IP21
INSULATION GRADE CLASS B CLASS B CLASS B CLASS B
RATED INPUT POWER W 181 284 284 393
RATED RUNNING CURRENT A 0.82 1.33 1.33 1.33
MOTOR OUTPUT W 90 320 320 320
POLES 4444
COIL
TUBE
MATERIAL COPPER COPPER COPPER COPPER
DIAMETER mm 9.52 9.52 9.52 9.52
FIN
MATERIAL ALUMINIUM ALUMINIUM ALUMINIUM ALUMINIUM
FACE AREA m
2
0.203 0.24 0.24 0.24
ROW 3333
AIR QUALITY FILTER
TYPE
WASHABLE SARANET
FILTER
WASHABLE SARANET
FILTER
WASHABLE SARANET
FILTER
WASHABLE SARANET
FILTER
QUANTITY pc 1222
CASING COLOUR
WITHOUT POWDER
PAINT
WITHOUT POWDER
PAINT
WITHOUT POWDER
PAINT
WITHOUT POWDER
PAINT
OUTDOOR UNIT
AIR FLOW l/s / CFM 755 / 1600 741 / 1570 1605 / 3400 1605 / 3400
SOUND PRESSURE LEVEL dBA 52 58 58 58
UNIT DIMENSION HEIGHT X WIDTH X DEPTH mm 753 x 855 x 328 753 x 855 x 328 852 x 1030 x 400 852 x 1030 x 400
PACKING DIMENSION HEIGHT X WIDTH X DEPTH mm 810 x 990 x 415 810 x 990 x 415 1010 x 1180 x 514 1010 x 1180 x 514
UNIT WEIGHT kg 57 57 95 95
PIPE
CONNECTION
TYPE FLARE VALVE FLARE VALVE FLARE VALVE FLARE VALVE
SIZE
LIQUID mm 9.52 9.52 9.52 9.52
GAS mm 15.88 15.88 15.88 15.88
FAN
TYPE PROPELLER PROPELLER PROPELLER PROPELLER
DRIVE DIRECT DIRECT DIRECT DIRECT
FAN MOTOR
TYPE INDUCTION INDUCTION INDUCTION INDUCTION
INDEX OF PROTECTION (IP) IP23 IP23 IP54 IP54
INSULATION GRADE CLASS F CLASS F CLASS F CLASS F
RATED INPUT POWER W 123 124 257 257
RATED RUNNING CURRENT A 0.53 0.54 1.10 1.10
MOTOR OUTPUT W 60 66 145 145
POLES 6688
COMPRESSOR
TYPE ROTARY ROTARY SCROLL SCROLL
OIL TYPE
ATMOS NM56M or
SUNISO 4GDID
ATMOS M60 or SUNISO
4GDID
MINERAL
(Sontex 200 LT)
MINERAL
(Sontex 200 LT)
OIL AMOUNT cm
3
670 1130 1240 1240
R
RATED INPUT POWER (COOLING) W 2312 2683 2280 -
RATED RUNNING CURRENT
(COOLING)
A 10.30 13.20 10.50 -
RY
RATED INPUT POWER (COOLING) W 2312 2683 2549 2420
RATED INPUT POWER (HEATING) W 2232 2230 2519 2390
RATED RUNNING CURRENT
(COOLING)
A 10.30 13.20 12.30 4.29
RATED RUNNING CURRENT
(HEATING)
A 10.10 11.50 12.20 4.19
LOCKED ROTOR AMP. A 56 62 82 40
COIL
TUBE
MATERIAL COPPER COPPER COPPER COPPER
DIAMETER mm 7.00 7.00 9.52 9.52
FIN
MATERIAL ALUMINIUM ALUMINIUM ALUMINIUM ALUMINIUM
FACE AREA m
2
0.203 0.240 0.870 0.870
ROW 3322
CASING COLOUR LIGHT GREY LIGHT GREY LIGHT GREY LIGHT GREY
ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151 (NON-DUCTED UNIT) OR ISO 13253 (DUCTED UNIT).
COOLING HEATING
INDOOR: 27°C DB / 19°C WB INDOOR: 20°C DB
OUTDOOR: 35°C DB / 24°C WB OUTDOOR: 7°C DB / 6°C WB
ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
