Engineering & Physical Data
Engineering & Physical Data
Engineering Data – R22 MODEL
MODEL
INDOOR UNIT FDM10CXV1 FDM15CXV1 FDM20CXV1
OUTDOOR UNIT R10CXV1 R15CXV1 R20CXV1
NOMINAL COOLING CAPACITY
Btu/h 9500 12300 19000
W 2780 3600 5570
NOMINAL TOTAL INPUT POWER (COOLING) W 900 1267 1895
NOMINAL RUNNING CURRENT (COOLING) A 4.02 5.68 8.33
EER W/W 3.17 2.94 3.05
REFRIGERANT CONTROL (EXPANSION DEVICE) OUTDOOR CAP. TUBE OUTDOOR CAP. TUBE OUTDOOR CAP. TUBE
REFRIGERANT CHARGE kg 0.63 0.75 1.35
MODEL
INDOOR UNIT FDYM10CXV1 FDYM15CXV1 FDYM20CXV1 FDYM20CXV1
OUTDOOR UNIT RY10CXV1 RY15CXV1 RY18CXV1 RY20CXV1
NOMINAL COOLING CAPACITY
Btu/h 9500 12300 18000 19000
W 2780 3600 5280 5570
NOMINAL HEATING CAPACITY
Btu/h 9500 12000 18500 19800
W 2780 3515 5420 5800
NOMINAL TOTAL INPUT POWER (COOLING) W 900 1267 1910 1895
NOMINAL TOTAL INPUT POWER (HEATING) W 790 1062 1750 1745
NOMINAL RUNNING CURRENT (COOLING) A 4.02 5.68 8.50 8.33
NOMINAL RUNNING CURRENT (HEATING) A 3.52 4.78 7.80 8.13
EER W/W 3.17 2.94 2.87 3.05
COP W/W 3.63 3.44 3.23 3.27
REFRIGERANT CONTROL (EXPANSION DEVICE) OUTDOOR CAP. TUBE OUTDOOR CAP. TUBE OUTDOOR CAP. TUBE OUTDOOR CAP. TUBE
REFRIGERANT CHARGE kg 0.63 0.93 0.85 1.35
POWER SOURCE V/Ph/Hz 220-240/1/50 220-240/1/50 220 - 240 / 1 / 50 220-240/1/50
REFRIGERANT TYPE R22 R22 R22 R22
INDOOR UNIT
CONTROL
AIR DISCHARGE DUCTED DUCTED DUCTED DUCTED
OPERATION SLM WIRED HANDSET SLM WIRED HANDSET SLM WIRED HANDSET SLM WIRED HANDSET
AIR FLOW
HIGH l/s / CFM 142/300 241/510 330 / 700 330 / 700
MEDIUM l/s / CFM 135/285 231/490 319 / 675 319/ 675
LOW l/s / CFM 123/260 189/400 302 / 640 302/ 640
EXTERNAL STATIC PRESSURE (H/M/L) Pa (in.wg.)
49 / 44 / 36
(0.2 / 0.18 / 0.14)
49 / 42 / 28
(0.2 / 0.17 / 0.11)
49 / 45 / 41
(0.2 / 0.18 / 0.16)
49 / 45 / 41
(0.2 / 0.18 / 0.16)
SOUND PRESSURE LEVEL (H/M/L) dBA 36 / 35 / 33 40 / 38/ 33 42 / 41 / 40 42 / 41 / 40
UNIT DIMENSION HEIGHT X WIDTH X DEPTH mm 261 x 765 x 411 261 x 905 x 411 261 x 1065 x 411 261 x 1065 x 411
PACKING DIMENSION HEIGHT X WIDTH X DEPTH mm 376 x 951 x 541 376 x 1091 x 541 376 x 1251 x 541 376 x 1251 x 541
UNIT WEIGHT kg 17 21 22 22
CONDENSATE DRAIN SIZE mm 19.1 19.1 19.1 19.1
FAN
TYPE CENTRIFUGAL CENTRIFUGAL CENTRIFUGAL CENTRIFUGAL
DRIVE DIRECT DIRECT DIRECT DIRECT
FAN MOTOR
TYPE INDUCTION INDUCTION INDUCTION INDUCTION
INDEX OF PROTECTION (IP) IP20 IP20 IP20 IP20
INSULATION GRADE CLASS B CLASS B CLASS B CLASS B
RATED INPUT POWER W 89 160 170 170
RATED RUNNING CURRENT A 0.40 0.78 0.79 0.79
MOTOR OUTPUT W 38 72 80 80
POLES 4466
COIL
TUBE
MATERIAL COPPER COPPER COPPER COPPER
DIAMETER mm 9.52 9.52 9.52 9.52
FIN
MATERIAL ALUMINIUM ALUMINIUM ALUMINIUM ALUMINIUM
FACE AREA m
2
0.115 0.143 0.176 0.176
ROW 3333
AIR QUALITY FILTER
TYPE
WASHABLE SARANET FILTER WASHABLE SARANET FILTER WASHABLE SARANET FILTER WASHABLE SARANET FILTER
QUANTITY pc 1111
CASING COLOUR
WITHOUT POWDER PAINT WITHOUT POWDER PAINT WITHOUT POWDER PAINT WITHOUT POWDER PAINT
OUTDOOR UNIT
AIR FLOW l/s / CFM 396 / 840 453 / 960 614 / 1300 614 / 1300
SOUND PRESSURE LEVEL dBA 46 49 51 51
UNIT DIMENSION HEIGHT X WIDTH X DEPTH mm 540 x 700 x 250 540 x 700 x 250 651 x 855 x 328 651 x 855 x 328
PACKING DIMENSION HEIGHT X WIDTH X DEPTH mm 620 x 810 x 330 620 x 810 x 330 810 x 990 x 415 810 x 990 x 415
UNIT WEIGHT
COOLING ONLY
kg
28 28 - 47
HEATPUMP 30 30 43 47
PIPE
CONNECTION
TYPE FLARE VALVE FLARE VALVE FLARE VALVE FLARE VALVE
SIZE
LIQUID mm 6.35 6.35 6.35 6.35
GAS mm 9.52 12.70 15.88 15.88
FAN
TYPE PROPELLER PROPELLER PROPELLER PROPELLER
DRIVE DIRECT DIRECT DIRECT DIRECT
FAN MOTOR
TYPE INDUCTION INDUCTION INDUCTION INDUCTION
INDEX OF PROTECTION (IP) IP23 IP23 IP23 IP23
INSULATION GRADE CLASS B CLASS B CLASS F CLASS F
RATED INPUT POWER W 57 76 77 80
RATED RUNNING CURRENT A 0.25 0.33 0.34 0.36
MOTOR OUTPUT W 21 30 32 32
POLES 6666
COMPRESSOR
TYPE ROTARY ROTARY ROTARY ROTARY
OIL TYPE
ATMOS NM56M or
SUNISO 4GDID
ATMOS NM56M or
SUNISO 4GDID
ATMOS NM56M or
SUNISO 4GDID
ATMOS NM56M or
SUNISO 4GDID
OIL AMOUNT cm
3
320 350 670 670
R
RATED INPUT POWER (COOLING) W 754 1031 - 1645
RATED RUNNING CURRENT (COOLING)
A 3.37 4.57 - 7.18
RY
RATED INPUT POWER (COOLING) W 754 1031 1663 1645
RATED INPUT POWER (HEATING) W 644 826 1503 1495
RATED RUNNING CURRENT (COOLING)
A 3.37 4.57 7.37 7.18
RATED RUNNING CURRENT (HEATING)
A 2.87 3.67 6.67 6.98
LOCKED ROTOR AMP. A 20 25 32 34
COIL
TUBE
MATERIAL COPPER COPPER COPPER COPPER
R DIAMETER mm 7.00 7.00 7.00 7.00
RY DIAMETER mm 7.00 9.52 7.00 7.00
FIN
MATERIAL ALUMINIUM ALUMINIUM ALUMINIUM ALUMINIUM
FACE AREA m
2
0.36 0.36 0.52 0.52
ROW 1112
CASING COLOUR LIGHT GREY LIGHT GREY LIGHT GREY LIGHT GREY
ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151 (NON-DUCTED UNIT) OR ISO 13253 (DUCTED UNIT).
COOLING HEATING
INDOOR: 27°C DB / 19°C WB INDOOR: 20°C DB
OUTDOOR: 35°C DB / 24°C WB OUTDOOR: 7°C DB / 6°C WB
ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
