a)
b)
c)
d)
Strap
Starp Cutter
Top corrugated
cardboard sheet with
EPS
Bottom corrugated
cardboard sheet
with EPS
❶
12. Unpacking & Packing of the Indoor
12-1 Unit Unpacking
• Cut all the straps (a) from the unit
using strap cutter(b) as shown in
figure.
❷
• Remove top corrugated cardboard
sheet(c) & EPS from the unit by
pulling it up as shown in figure.
❸
c
b
a
a
a
a
d
• Remove the bottom corrugated cardboard
sheet(d) & EPS from the unit by pulling the unit
up as shown in figure, then remove the
polythene product cover.
19
