Daikin FDMF48AVMK - Page 8

7
Installtion
kit
pipe size
12.7
Installtion kit
Flare End
OA
OB
140
90
AA
AB
PART
1
2
Dia at AA
ø 9.52 X t0.8
ø 15.9 X t1.0
Dia at AB
ø 12.7 X t 1mm
ø 22.2 X t1 mm
Table
Installtion kit
auxiliary pipe.
22.2
ø 9.52
to
12.7
ø 15.9
to
22.2
