Daikin FDR200FRY16 - Vacuuming and Charging; Vacuuming Procedure; Charging Procedure; System Refrigerant Charge Level Guidelines

R410A
Indoor Outdoor Liquid Pipe Gas Pipe
Refrigerant
Charge
(kg/7.5m pipe
length)
FDR100FRV16
FDR130FRV16
FDR130FRV162
FDR200FRY16
RR100FRY16
RR130FRY16
2*RR65FRY16
2*RR100FRY16
1/2"
5/8"
1/2"
1/2"
5.3
8.4
2*4.4
2*5.9
1-1/8"
1-1/8"
7/8"
1-1/8"
FDR65FRV16 RR65FRY16
1/2"
4.4
7/8"
FDMR36ERV16 RR36ERY16 3/8" 2.655/8"
FD100DSV16
FD130DSV16
R100DSY16
R130DSY16
1/2"
5/8"
6.0
8.7
1-1/8"
1-3/8"
FD65DSV16 R65DSY16
1/2"
3.9
7/8"
FD200DSY16 2*R100DSY16
1/2"
2*6.0
1-1/8"
right type
type
18
FD90GRV16
FD120GRV16
R90GRY16
R120GRY16
1/2"
5/8"
6.0
9.1
1-1/8"
1-3/8"
FD60GRV16 R60GRY16
1/2"
4.0
7/8"
FD180GRY16 2*R90GRY16
1/2"
2*6.7
1-1/8"
* FDR200FRY16 comes with 2 Nos. of RR100FRY16, where standard gas charge is 5.3kg/unit.
Extra 0.6Kg should be charged for standard pipe length in each unit during installation in field.
* FD180GRY16 comes with 2 Nos. of R90GRY16, where standard gas charge is 6.0kg/unit.
Extra 0.7Kg should be charged for standard pipe length in each unit during installation in field.
