ii
Outdoor Unit
All dimensions are in mm/(in)
Dimension A B C D E F G H I J K L M N O
RY30CV1M 700 521 250 485 175 36 95 93 86 68 441 130 111 15 18
RY40CV1M (27,5) (20,5) (9,8) (19,1) (6,8) (1,4) (3,7) (3,6) (3,3) (2,6) (17,3) (5,1) (4,3) (0,5) (0,7)
30
(1,2)
(0,1)
3
(0,7)
19
(2,6)
65
(3,1)
80
L
KL
N
CN
M
F
E
C
G
H
IJ
A
D
O
B
Dimension A B C D E F G H I J K L M N O
RY60CV1M
855 628 328 513 182 44 93 149 101 113 603 126 164 17 49
(33,7) (24,7) (12,9) (20,0) (7,1) (1,7) (3,7) (5,9) (4,0) (4,4) (23,7) (5,0) (6,4) (0,7) (1,9)
RY71CV1M 855 730 328 513 182 44 93 149 101 113 603 126 164 17 47
RY80CV1M (33,7) (28,7) (12,9) (20,2) (7,2) (1,7) (3,7) (5,9) (4,0) (4,4) (23,7) (5,0) (6,4) (0,7) (1,9)
All dimensions are in mm/ (in)
Outdoor Unit
Dimension P Q R S T
RY60CV1M
32 3 23 73 75
(1,3) (0,1) (0,9) (2,9) (3,0)
RY71CV1M 32 3 23 73 75
RY80CV1M (1,3) (0,1) (0,9) (2,9) (3,0)
KL
C
M
N
A
D
N
P
FE
C
GH
B
Q
R
O
L
ST
IJ
