Outdoor Unit
Model A B C D E F G H J K L M N P
RY90CV1M/ RY90CY1M/ 1030 850 400 390 414 827 72 196 91 488 448 141,5 746,5 82
RY100CV1M/ RY125CV1M/ (40,6) (33,5) (15,7) (15,4) (16,3) (32,6) (2,8) (7,7) (3,6) (19,2) (17,6) (5,6) (29,4) (3,2)
RY125CY1M/ RY140CY1M
All dimensions are in mm/(in)
J
H
C
G
E
F
B
D
NM
A
L
K
P
