Model A B C D E F G H J K L M N
RY160CY1M 1030 850 400 448 746,5 320 25 50 85 40 141.5 20 60
(40,6) (33,5) (15,7) (17,6) (29,4) (12,6) (1,0) (2,0) (3,3) (1,6) (5,6) (0,8) (2,4)
All dimensions are in mm/(in)
J
H
C
FK
K
B
G
A
LEL
M
D
M
N
