Daikin FFQ25C - 2 Specifications; Technical Specifications

3
2
• Split - Sky Air • FFQ-C
3
• Indoor Unit • FFQ-C
2 Specifications
2-1 Technical Specifications FFQ25C FFQ35C FFQ50C FFQ60C
Casing Material Galvanised steel plate
Dimensions Unit Height/Width/
Depth
mm 260/575/575
Packed unit Height/Width/
Depth
mm 270/780/616
Weight Unit kg 16 17.5
Packed unit kg 19 20.5
Decoration panel Model BYFQ60CW
Colour White (N9.5)
Dimensions Height/Width/
Depth
mm 46/620/620
Weight kg 2.8
Decoration panel 2 Model BYFQ60CS
Colour White (N9.5) + Silver
Dimensions Height/Width/
Depth
mm 46/620/620
Weight kg 2.8
Decoration panel 3 Model BYFQ60B3W1
Colour White (RAL9010)
Dimensions Height/Width/
Depth
mm 55/700/700
Weight kg 2.7
Heat exchanger Inside length mm 1,295 1,248
Outside length mm 1,342
Rows Quantity 2 3
Fin pitch mm 1.2
Passes Quantity 5 7
Face area m² 0.290 0.300
Stages Quantity 12 16
Empty tubeplate
hole
Quantity 0
Fin Type Cross fin coil (multi slit fins and hi-XA tubes)
Air filter Type Resin net with mold resistance
Fan Type Turbo fan
Quantity 1
Air flow rate Cooling High m³/min 9 10 12 14.5
Nom. m³/min 8 8.5 10 12.5
Low m³/min 6.5 7.5 9.5
Heating High m³/min 9 10 12 14.5
Nom. m³/min 8 8.5 10 12.5
Low m³/min 6.5 7.5 9.5
Fan motor Model QTS32D15M
Speed Steps 3
Output High W 50
Sound power level Cooling dBA 48 51 56 60
Heating dBA -
Sound pressure level Cooling High/Nom./Low dBA 31/28.5/25 34/30.5/25 39/34/27 43/40/32
Heating High/Nom./Low dBA 31/28.5/25 34/30.5/25 39/34/27 43/40/32
Control systems Infrared remote control BRC7EB530 (standard panel) / BRC7F530W (white panel) / BRC7F530S (grey panel)
Wired remote control BRC1D52 / BRC1E52A/B
Refrigerant Type R-410A
Piping connections Sound absorbing insulation Foamed Polyurethane
Liquid Type/OD mm Flare connection/6.35
Gas Type/OD mm Flare connection/9.52 Flare connection/12.7
Drain VP20 (I.D. 20/O.D. 26)
Heat insulation Foamed polystyrene/polyethylene
