Application Information
Model: FHC28EXV1 – R28CXV1
STRAINER
COOLING OPERATION
3 WAY
VALVE
DISCHARGE
ACCUMULATOR
COMPRESSOR
RETURN
AIR SENSOR
HEAT EXCHANGER
(INDOOR UNIT)
PIPE TEMPERATURE
SENSOR
3 WAY
VALVE
COOLING
CAP TUBE
HEAT EXCHANGER
(OUTDOOR UNIT)
INDOOR UNIT OUTDOOR UNIT
Model: FHC40EXV1 – R35DXV1 / FHC40EXV1 – R40DXV1 / FHC40EXV1 – R40DXY1 /
FHC50EXV1 – R50DXY1
STRAINER
COOLING OPERATION
3 WAY
VALVE
DISCHARGE
LOW
PRESSURE
SWITCH
ACCUMULATOR
RETURN
AIR SENSOR
HEAT EXCHANGER
(INDOOR UNIT)
PIPE TEMPERATURE
SENSOR
3 WAY
VALVE
CAP TUBE
HEAT EXCHANGER
(OUTDOOR UNIT)
INDOOR UNIT OUTDOOR UNIT
COMPRESSOR
HIGH
PRESSURE
SWITCH
