43
Performance Data
Model: FHYC25EXV1 - RY25CXV1
Cooling Mode
AFR
(CFM)
EWB EDB
Outdoor temperature
19°C 25°C 30°C 35°C 40°C 46°C
TC SC PI TC SC PI TC SC PI TC SC PI TC SC PI TC SC PI
530
16°C
21°C 6.91 4.63 1.93 6.67 4.51 2.09 6.42 4.38 2.26 6.16 4.26 2.45 5.66 3.96 2.66 5.22 3.73 2.93
24°C 6.92 5.54 1.93 6.68 5.41 2.09 6.43 5.29 2.26 6.17 5.16 2.45 5.67 4.81 2.66 5.24 4.54 2.93
27°C 6.98 6.28 1.93 6.74 6.14 2.09 6.51 5.99 2.27 6.26 5.84 2.46 5.78 5.43 2.67 5.38 5.10 2.94
30°C 7.19 7.19 1.94 6.98 6.98 2.10 6.77 6.77 2.28 6.55 6.55 2.48 6.08 6.08 2.69 5.68 5.68 2.97
19°C
24°C 7.62 4.32 1.96 7.36 4.21 2.12 7.09 4.10 2.30 6.81 3.98 2.49 6.25 3.71 2.71 5.78 3.49 2.98
27°C 7.63 4.94 1.96 7.36 4.83 2.12 7.09 4.72 2.30 6.81 4.61 2.49 6.26 4.31 2.71 5.79 4.08 2.98
30°C 7.64 6.10 1.96 7.38 5.97 2.12 7.12 5.84 2.30 6.85 5.70 2.50 6.30 5.33 2.71 5.85 5.04 2.99
33°C 7.73 7.73 1.97 7.48 7.48 2.13 7.24 7.24 2.31 6.99 6.99 2.51 6.47 6.47 2.72 6.05 6.05 3.01
22°C
27°C 8.39 4.23 2.00 8.10 4.13 2.16 7.80 4.02 2.34 7.50 3.91 2.54 6.89 3.64 2.76 6.38 3.44 3.04
30°C 8.39 5.15 2.00 8.10 5.04 2.16 7.80 4.93 2.34 7.50 4.81 2.54 6.90 4.50 2.76 6.38 4.27 3.04
33°C 8.39 6.02 2.00 8.10 5.90 2.16 7.81 5.78 2.34 7.50 5.67 2.54 6.91 5.32 2.76 6.40 5.05 3.04
36°C 8.42 6.82 2.00 8.14 6.69 2.17 7.86 6.55 2.35 7.58 6.40 2.55 6.99 6.00 2.77 6.50 5.69 3.05
600
16°C
21°C 7.19 4.82 1.95 6.93 4.70 2.11 6.67 4.57 2.28 6.40 4.45 2.47 5.87 4.14 2.68 5.41 3.90 2.96
24°C 7.21 5.86 1.95 6.95 5.72 2.11 6.69 5.58 2.28 6.42 5.44 2.48 5.90 5.08 2.68 5.45 4.79 2.96
27°C 7.30 6.65 1.95 7.05 6.50 2.11 6.81 6.33 2.29 6.57 6.14 2.48 6.06 5.70 2.70 5.65 5.33 2.98
30°C 7.60 7.60 1.97 7.38 7.38 2.13 7.16 7.16 2.31 6.93 6.93 2.51 6.42 6.42 2.72 6.00 6.00 3.01
19°C
24°C 7.92 4.56 1.98 7.64 4.45 2.14 7.35 4.33 2.32 7.06 4.21 2.52 6.48 3.93 2.73 5.99 3.70 3.01
27°C 7.94 5.26 1.98 7.65 5.14 2.14 7.37 5.02 2.32 7.07 4.90 2.52 6.50 4.59 2.73 6.01 4.34 3.01
30°C 7.97 6.48 1.98 7.70 6.34 2.15 7.42 6.20 2.33 7.14 6.05 2.52 6.57 5.66 2.74 6.10 5.34 3.02
33°C 8.11 8.11 1.99 7.86 7.86 2.15 7.61 7.61 2.34 7.36 7.36 2.54 6.81 6.81 2.76 6.37 6.37 3.04
22°C
27°C 8.70 4.47 2.02 8.40 4.36 2.18 8.09 4.25 2.37 7.76 4.14 2.57 7.14 3.86 2.78 6.60 3.64 3.07
30°C 8.72 5.48 2.02 8.41 5.37 2.18 8.09 5.25 2.37 7.77 5.13 2.57 7.14 4.80 2.78 6.61 4.56 3.07
33°C 8.73 6.42 2.02 8.43 6.30 2.19 8.12 6.17 2.37 7.80 6.04 2.57 7.17 5.67 2.79 6.65 5.38 3.07
36°C 8.78 7.26 2.02 8.50 7.13 2.19 8.20 6.98 2.38 7.91 6.81 2.58 7.29 6.38 2.80 6.80 6.02 3.09
680
16°C
21°C 7.46 5.03 1.96 7.18 4.91 2.12 6.91 4.78 2.30 6.62 4.64 2.49 6.07 4.32 2.70 5.60 4.07 2.98
24°C 7.50 6.12 1.97 7.22 5.97 2.13 6.95 5.83 2.30 6.67 5.67 2.50 6.13 5.29 2.71 5.66 4.99 2.98
27°C 7.62 7.01 1.97 7.37 6.83 2.13 7.12 6.64 2.31 6.86 6.43 2.51 6.34 5.96 2.72 5.91 5.56 3.01
30°C 8.00 8.00 1.99 7.76 7.76 2.15 7.53 7.53 2.34 7.28 7.28 2.54 6.74 6.74 2.76 6.29 6.29 3.04
19°C
24°C 8.21 4.83 2.00 7.91 4.71 2.16 7.61 4.59 2.34 7.30 4.46 2.54 6.70 4.16 2.75 6.19 3.93 3.03
27°C 8.23 5.59 2.00 7.94 5.46 2.16 7.64 5.33 2.34 7.33 5.20 2.54 6.73 4.86 2.75 6.22 4.60 3.04
30°C 8.30 6.87 2.00 8.01 6.72 2.17 7.72 6.57 2.35 7.42 6.41 2.55 6.84 5.98 2.76 6.35 5.64 3.05
33°C 8.48 8.48 2.01 8.23 8.23 2.18 7.98 7.98 2.36 7.72 7.72 2.57 7.15 7.15 2.79 6.68 6.68 3.08
22°C
27°C 9.01 4.72 2.03 8.69 4.62 2.20 8.36 4.50 2.39 8.02 4.39 2.59 7.37 4.09 2.81 6.81 3.86 3.09
30°C 9.03 5.82 2.03 8.70 5.71 2.20 8.38 5.59 2.39 8.04 5.46 2.59 7.39 5.11 2.81 6.83 4.85 3.09
33°C 9.06 6.82 2.04 8.74 6.70 2.21 8.42 6.56 2.39 8.09 6.42 2.59 7.44 6.02 2.81 6.90 5.71 3.10
36°C 9.14 7.70 2.04 8.85 7.56 2.21 8.54 7.40 2.40 8.24 7.22 2.60 7.61 6.73 2.83 7.10 6.34 3.12
Model: FHYC25EXV1 - RY25CXV1
Heating Mode
ID DB
Outdoor WB
-9°C -6°C -5°C 6°C 12°C 15°C 18°C
TC (kW) SC (kW) TC (kW) SC (kW) TC (kW) SC (kW) TC (kW) SC (kW) TC (kW) SC (kW) TC (kW) SC (kW) TC (kW) SC (kW)
15°C 4.431 4.431 5.015 5.015 5.210 5.210 7.352 7.352 8.520 8.520 9.104 9.104 9.689 9.689
17°C 4.315 4.315 4.660 4.660 5.085 5.085 7.343 7.343 8.357 8.357 8.934 8.934 9.512 9.512
19°C 4.199 4.199 4.305 4.305 4.960 4.960 7.334 7.334 8.194 8.194 8.764 8.764 9.335 9.335
21°C 4.083 4.083 4.149 4.149 4.835 4.835 7.205 7.205 8.030 8.030 8.594 8.594 9.158 9.158
23°C 3.967 3.967 4.192 4.192 4.709 4.709 6.954 6.954 7.867 7.867 8.424 8.424 8.982 8.982
25°C 3.850 3.850 4.235 4.235 4.584 4.584 6.704 6.704 7.704 7.704 8.254 8.254 8.805 8.805
27°C 3.734 3.734 4.278 4.278 4.459 4.459 6.453 6.453 7.540 7.540 8.084 8.084 8.628 8.628
Frost Region
Remark:
AFR: Air fl ow rate (CFM)
EWB: Entering Wet Bulb Temp. (°C)
EDB: Entering Dry Bulb Temp. (°C)
TC: Total Cooling / Heating Capacity (kW)
SC: Sensible Cooling / Heating Capacity (kW)
PI: Power Input (kW)
Notes:
1. Ratings shown are net capacities.
2. shows nominal capacities.
3. Direct interpolation is permissible. Do not extrapolate.
4. Unit is able to operate at ambient from 19°C to 46°C DB (cooling) / -9°C to 18°C WB (heating) without pressure trip.
