Performance Data
Model: FHYC50EXV1 - RY50DXY1
Cooling Mode
AFR
(CFM)
EWB EDB
Outdoor temperature
19°C 25°C 30°C 35°C 40°C 46°C
TC SC PI TC SC PI TC SC PI TC SC PI TC SC PI TC SC PI
930
16°C
21°C
13.30
9.03 3.65
12.83
8.79 3.94
12.35
8.56 4.27
11.85
8.31 4.63
10.88
7.73 5.02
10.05
7.28 5.54
24°C
13.31 10.81
3.65
12.84 10.56
3.95
12.36 10.32
4.27
11.87 10.06
4.63
10.91
9.40 5.03
10.09
8.87 5.54
27°C
13.42 12.26
3.65
12.97 11.98
3.95
12.52 11.70
4.28
12.04 11.40
4.64
11.11 10.61
5.04
10.34
9.96 5.56
30°C
13.83 13.83
3.67
13.43 13.43
3.97
13.03 13.03
4.31
12.61 12.61
4.68
11.69 11.69
5.08
10.93 10.93
5.62
19°C
24°C
14.67
8.43 3.71
14.15
8.22 4.01
13.63
8.00 4.35
13.09
7.77 4.71
12.03
7.24 5.11
11.12
6.82 5.63
27°C
14.67
9.65 3.71
14.16
9.43 4.01
13.64
9.21 4.35
13.10
8.99 4.71
12.04
8.41 5.11
11.14
7.97 5.64
30°C
14.70 11.90
3.71
14.19 11.65
4.01
13.69 11.39
4.35
13.17 11.12
4.72
12.13 10.40
5.12
11.25
9.84 5.65
33°C
14.87 14.87
3.72
14.39 14.39
4.02
13.92 13.92
4.36
13.45 13.45
4.74
12.44 12.44
5.14
11.63 11.63
5.68
22°C
27°C
16.13
8.25 3.77
15.58
8.05 4.09
15.01
7.85 4.43
14.42
7.63 4.81
13.26
7.11 5.21
12.28
6.71 5.74
30°C
16.14 10.06
3.77
15.58
9.84 4.09
15.01
9.62 4.43
14.42
9.39 4.81
13.27
8.79 5.21
12.28
8.33 5.74
33°C
16.15 11.74
3.77
15.59 11.52
4.09
15.02 11.29
4.43
14.43 11.06
4.81
13.28 10.38
5.21
12.31
9.86 5.75
36°C
16.20 13.32
3.78
15.67 13.05
4.09
15.12 12.78
4.44
14.57 12.50
4.82
13.44 11.72
5.23
12.49 11.12
5.76
1030
16°C
21°C
13.83
9.41 3.68
13.33
9.17 3.98
12.83
8.93 4.31
12.30
8.68 4.67
11.29
8.08 5.07
10.41
7.60 5.59
24°C
13.87 11.43
3.68
13.37 11.16
3.98
12.87 10.89
4.31
12.35 10.62
4.68
11.35
9.91 5.07
10.49
9.35 5.59
27°C
14.04 12.98
3.69
13.57 12.68
3.99
13.10 12.35
4.33
12.63 11.98
4.69
11.66 11.13
5.10
10.86 10.41
5.62
30°C
14.63 14.63
3.72
14.20 14.20
4.02
13.77 13.77
4.37
13.32 13.32
4.74
12.34 12.34
5.15
11.54 11.54
5.69
19°C
24°C
15.24
8.91 3.74
14.70
8.68 4.05
14.14
8.46 4.39
13.58
8.22 4.76
12.47
7.66 5.16
11.52
7.22 5.68
27°C
15.27 10.26
3.74
14.72 10.03
4.05
14.17
9.81 4.39
13.60
9.57 4.76
12.50
8.95 5.16
11.55
8.47 5.69
30°C
15.34 12.66
3.75
14.80 12.38
4.06
14.27 12.11
4.39
13.73 11.81
4.77
12.64 11.04
5.17
11.73 10.43
5.70
33°C
15.59 15.59
3.76
15.12 15.12
4.07
14.64 14.64
4.42
14.15 14.15
4.80
13.11 13.11
5.21
12.26 12.26
5.75
22°C
27°C
16.74
8.72 3.81
16.15
8.52 4.13
15.55
8.30 4.47
14.94
8.08 4.85
13.72
7.53 5.26
12.69
7.11 5.79
30°C
16.76 10.70
3.81
16.17 10.48
4.13
15.57 10.25
4.47
14.95 10.01
4.85
13.74
9.37 5.26
12.71
8.89 5.80
33°C
16.79 12.54
3.81
16.21 12.30
4.13
15.62 12.05
4.48
15.00 11.79
4.86
13.80 11.06
5.27
12.79 10.50
5.80
36°C
16.90 14.18
3.82
16.35 13.91
4.14
15.78 13.62
4.49
15.21 13.30
4.87
14.03 12.45
5.29
13.08 11.74
5.83
1200
16°C
21°C
14.34
9.83 3.71
13.82
9.58 4.01
13.29
9.32 4.34
12.74
9.06 4.71
11.68
8.44 5.11
10.77
7.94 5.63
24°C
14.42 11.94
3.71
13.90 11.66
4.02
13.37 11.37
4.35
12.83 11.07
4.72
11.79 10.33
5.12
10.89
9.74 5.64
27°C
14.65 13.68
3.72
14.17 13.33
4.03
13.69 12.96
4.37
13.20 12.55
4.74
12.20 11.63
5.15
11.37 10.86
5.68
30°C
15.39 15.39
3.76
14.94 14.94
4.07
14.48 14.48
4.42
14.00 14.00
4.79
12.96 12.96
5.21
12.11 12.11
5.75
19°C
24°C
15.79
9.42 3.77
15.22
9.19 4.08
14.64
8.96 4.42
14.04
8.71 4.80
12.89
8.12 5.20
11.90
7.66 5.73
27°C
15.84 10.90
3.77
15.27 10.65
4.09
14.69 10.40
4.43
14.10 10.15
4.80
12.95
9.49 5.21
11.96
8.98 5.74
30°C
15.97 13.42
3.78
15.40 13.13
4.09
14.85 12.83
4.44
14.28 12.50
4.81
13.15 11.68
5.22
12.21 11.01
5.76
33°C
16.31 16.31
3.80
15.83 15.83
4.12
15.35 15.35
4.47
14.84 14.84
4.85
13.75 13.75
5.27
12.86 12.86
5.82
22°C
27°C
17.33
9.22 3.84
16.71
9.02 4.16
16.08
8.79 4.51
15.43
8.56 4.89
14.18
7.99 5.30
13.10
7.54 5.84
30°C
17.36 11.37
3.84
16.74 11.15
4.16
16.11 10.91
4.51
15.47 10.66
4.89
14.21
9.98 5.31
13.14
9.46 5.85
33°C
17.42 13.32
3.85
16.82 13.09
4.17
16.20 12.81
4.52
15.56 12.53
4.90
14.32 11.74
5.32
13.27 11.15
5.86
36°C
17.58 15.04
3.86
17.03 14.77
4.18
16.44 14.44
4.54
15.85 14.08
4.92
14.64 13.14
5.34
13.66 12.37
5.90
Model: FHYC50EXV1 - RY50DXY1
Heating Mode
ID DB
Outdoor WB
-9°C -6°C -5°C 6°C 12°C 15°C 18°C
TC (kW) SC (kW) TC (kW) SC (kW) TC (kW) SC (kW) TC (kW) SC (kW) TC (kW) SC (kW) TC (kW) SC (kW) TC (kW) SC (kW)
15°C 8.887 8.887 10.058 10.058 10.449 10.449 14.744 14.744 17.087 17.087 18.258 18.258 19.430 19.430
17°C 8.654 8.654 8.840 8.840 10.130 10.130 14.726 14.726 16.404 16.404 17.512 17.512 18.619 18.619
19°C 8.421 8.421 7.623 7.623 9.811 9.811 14.709 14.709 15.722 15.722 16.765 16.765 17.808 17.808
21°C 8.188 8.188 7.194 7.194 9.493 9.493 14.231 14.231 15.039 15.039 16.018 16.018 16.996 16.996
23°C 7.955 7.955 7.554 7.554 9.174 9.174 13.294 13.294 14.356 14.356 15.271 15.271 16.185 16.185
25°C 7.722 7.722 7.915 7.915 8.855 8.855 12.356 12.356 13.674 13.674 14.524 14.524 15.374 15.374
27°C 7.489 7.489 8.275 8.275 8.537 8.537 11.419 11.419 12.991 12.991 13.777 13.777 14.563 14.563
Frost Region
Remark:
AFR: Air fl ow rate (CFM)
EWB: Entering Wet Bulb Temp. (°C)
EDB: Entering Dry Bulb Temp. (°C)
TC: Total Cooling / Heating Capacity (kW)
SC: Sensible Cooling / Heating Capacity (kW)
PI: Power Input (kW)
Notes:
1. Ratings shown are net capacities.
2. shows nominal capacities.
3. Direct interpolation is permissible. Do not extrapolate.
4. Unit is able to operate at ambient from 19°C to 46°C DB (cooling) / -9°C to 18°C WB (heating) without pressure trip.
