Engineering & Physical Data
Engineering Data - R22 MODEL
MODEL
INDOOR UNIT FHC20EXV1 FHC25EXV1 FHC28EXV1 FHC40EXV1
OUTDOOR UNIT R20CXV1 R25CXV1 R28CXV1 R35CXV1
NOMINAL COOLING CAPACITY
Btu/h 19500 25000 27000 35000
W 5715 7327 7913 10258
NOMINAL TOTAL INPUT POWER (COOLING) W 1960 2540 2720 3010
NOMINAL RUNNING CURRENT (COOLING) A 8.77 11.50 12.30 14.40
EER W/W 2.92 2.88 2.91 3.41
REFRIGERANT CONTROL (EXPANSION DEVICE) OUTDOOR CAP. TUBE INDOOR CAP. TUBE
REFRIGERANT CHARGE kg 1.35 1.50 1.75 2.00
MODEL
INDOOR UNIT FHYC20EXV1 FHYC25EXV1 FHYC28EXV1 FHYC40EXV1
OUTDOOR UNIT RY20CXV1 RY25CXV1 RY28CXV1 RY35CXV1
NOMINAL COOLING CAPACITY
Btu/h 19500 25000 27000 35000
W 5715 7327 7913 10258
NOMINAL HEATING CAPACITY
Btu/h 19500 25000 28000 35000
W 5715 7327 8206 10258
NOMINAL TOTAL INPUT POWER (COOLING) W 1960 2540 2720 3010
NOMINAL TOTAL INPUT POWER (HEATING) W 1690 2310 2350 2750
NOMINAL RUNNING CURRENT (COOLING) A 8.77 11.50 12.30 14.40
NOMINAL RUNNING CURRENT (HEATING) A 7.56 10.40 10.90 13.40
EER W/W 2.92 2.88 2.91 3.41
COP W/W 3.38 3.17 3.49 3.73
REFRIGERANT CONTROL (EXPANSION DEVICE) OUTDOOR CAP. TUBE
OUTDOOR CAP.
TUBE + TXV
REFRIGERANT CHARGE kg 1.35 1.50 1.83 2.00
POWER SOURCE V/Ph/Hz 220 - 240 / 1/ 50
REFRIGERANT TYPE R22
INDOOR UNIT
CONTROL
AIR DISCHARGE 4 WAY AUTOMATIC LOUVER (UP & DOWN)
OPERATION WIRELESS MICROCOMPUTER REMOTE CONTROL
AIR FLOW
HIGH l/s / CFM 280 / 600 320 / 680 410 / 860 490 / 1030
MEDIUM l/s / CFM 250 / 530 280 / 600 340 / 725 410 / 860
LOW l/s / CFM 200 / 430 250 / 530 290 / 620 350 / 740
SUPER LOW l/s / CFM 190 / 400 200 / 430 250 / 530 295 / 620
SOUND PRESSURE LEVEL (H/M/L/SL) dBA 34 / 32 / 30 / 28 37 / 34 / 33 / 32 42 / 38 / 35 / 33 47 / 44 / 40 / 36
UNIT DIMENSION HEIGHT X WIDTH X DEPTH mm 265 X 820 X 820 300 X 820 X 820
PACKING DIMENSION HEIGHT X WIDTH X DEPTH mm 300 X 916 X 916 335 X 916 X 916
UNIT WEIGHT (UNIT + PANEL) kg 26 + 4 28 + 4 31 + 4 39 + 4
CONDENSATE DRAIN SIZE mm 19.05
FAN
TYPE TURBO
DRIVE DIRECT
FAN MOTOR
TYPE INDUCTION
INDEX OF PROTECTION (IP) IP20
INSULATION GRADE CLASS B
RATED INPUT POWER W 88 101 144 176
RATED RUNNING CURRENT A 0.39 0.44 0.63 0.79
MOTOR OUTPUT W 20 30 50 60
POLES 6
COIL
TUBE
MATERIAL COPPER
DIAMETER mm 7
FIN
MATERIAL ALUMINIUM
FACE AREA m
2
0.386 0.372 0.461
ROW 23
AIR QUALITY FILTER
TYPE WASHABLE SARANET FILTER
QUANTITY pc 1
CASING COLOUR WITHOUT PAINT
OUTDOOR UNIT
AIR FLOW l/s / CFM 614 / 1300 755 / 1600 741 / 1570 1605 / 3400
SOUND PRESSURE LEVEL dBA 51 52 58 58
UNIT DIMENSION HEIGHT X WIDTH X DEPTH mm 651 X 855 X 328 753 X 855 X 328 852 X 1030 X 400
PACKING DIMENSION HEIGHT X WIDTH X DEPTH mm 710 X 990 X 415 810 X 990 X 415 1010 X 1180 X 514
UNIT WEIGHT kg 47 57 57 95
PIPE
CONNECTION
TYPE FLARE VALVE
SIZE
LIQUID mm 6.35 9.52
GAS mm 15.88 19.05
FAN
TYPE PROPELLER
DRIVE DIRECT
FAN MOTOR
TYPE INDUCTION
INDEX OF PROTECTION (IP) IP23 IP54
INSULATION GRADE CLASS F CLASS B
RATED INPUT POWER (R) W 80 123 124 257
RATED INPUT POWER (RY) W 80 123 124 257
RATED RUNNING CURRENT (R) A 0.36 0.53 0.54 1.10
RATED RUNNING CURRENT (RY) A 0.36 0.53 0.54 1.10
MOTOR OUTPUT W 32 60 66 145
POLES 68
COMPRESSOR
TYPE ROTARY SCROLL
OIL TYPE ATMOS NM56M or SUNISO 4GDID MOBIL EAL
OIL AMOUNT cm
3
670 700 1130 1242
R RATED INPUT POWER W 1792 2316 2452 2577
RY
RATED INPUT POWER (COOLING) W 1792 2316 2452 2577
RATED INPUT POWER (HEATING) W 1522 2086 2082 2317
R RATED INPUT CURRENT A 8.02 10.53 11.13 12.51
RY
RATED INPUT CURRENT
(COOLING)
A 8.02 10.53 11.13 12.51
RATED INPUT CURRENT
(HEATING)
A 6.81 9.43 9.73 11.51
LOCKED ROTOR AMP. A 34 56 62 97
COIL
TUBE
MATERIAL COPPER
DIAMETER (R / RY) mm 7 9.52
FIN
MATERIAL ALUMINIUM
FACE AREA m
2
0.52 0.62 0.62 0.87
ROW 2
CASING COLOUR LIGHT GREY
ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151 (NON-DUCTED UNIT) OR ISO 13253 (DUCTED UNIT).
COOLING HEATING
INDOOR: 27°C DB/ 19°C WB INDOOR: 20°C DB
OUTDOOR: 35°C DB/ 24°C WB OUTDOOR: 7°C DB/ 6°C WB
