Engineering & Physical Data
Engineering Data - R22 MODEL
MODEL
INDOOR UNIT FHC40EXV1 FHC50EXV1
OUTDOOR UNIT R40DXV1 R40DXY1 R50DXY1
NOMINAL COOLING CAPACITY
Btu/h 39000 39500 49500
W 11430 11600 14500
NOMINAL TOTAL INPUT POWER (COOLING) W 3450 3650 4600
NOMINAL RUNNING CURRENT (COOLING) A 16.7 6.13 8.00
EER W/W 3.31 3.17 3.15
REFRIGERANT CONTROL (EXPANSION DEVICE) INDOOR CAP. TUBE
REFRIGERANT CHARGE kg 2.40 2.48 2.45
MODEL
INDOOR UNIT FHYC40EXV1 FHYC50EXV1
OUTDOOR UNIT RY40DXV1 RY40DXY1 RY50DXY1
NOMINAL COOLING CAPACITY
Btu/h 39500 48000
W 11600 14100
NOMINAL HEATING CAPACITY
Btu/h 42000 50000
W 12300 14700
NOMINAL TOTAL INPUT POWER (COOLING) W 3600 3500 4800
NOMINAL TOTAL INPUT POWER (HEATING) W 3250 3200 4200
NOMINAL RUNNING CURRENT (COOLING) A 17.40 6.09 8.20
NOMINAL RUNNING CURRENT (HEATING) A 15.90 6.08 7.48
EER W/W 3.22 3.31 2.93
COP W/W 3.79 3.85 3.49
REFRIGERANT CONTROL (EXPANSION DEVICE) OUTDOOR CAP. TUBE
REFRIGERANT CHARGE kg 2.60 2.50
POWER SOURCE V/Ph/Hz 220 - 240 / 1/ 50 380 - 415 / 3 / 50
REFRIGERANT TYPE R22
INDOOR UNIT
CONTROL
AIR DISCHARGE 4 WAY AUTO LOUVER (UP & DOWN)
OPERATION WIRELESS MICROCOM. REMOTE CONTROL
AIR FLOW
HIGH l/s / CFM 490 / 1030 570 / 1200
MEDIUM l/s / CFM 410 / 860 490 / 1030
LOW l/s / CFM 350 / 740 440 / 930
SUPER LOW l/s / CFM 295 / 620 370 / 780
SOUND PRESSURE LEVEL (H/M/L/SL) dBA 47 / 44 / 40 / 36 49 / 45 / 43 / 39
UNIT DIMENSION HEIGHT X WIDTH X DEPTH mm 300 X 820 X 820
PACKING DIMENSION HEIGHT X WIDTH X DEPTH mm 335 X 916 X 916
UNIT WEIGHT (UNIT + PANEL) kg 39 + 4 41 + 4
CONDENSATE DRAIN SIZE mm 19.05
FAN
TYPE TURBO
DRIVE DIRECT
FAN MOTOR
TYPE INDUCTION
INDEX OF PROTECTION (IP) IP20
INSULATION GRADE CLASS B
RATED INPUT POWER W 176 221
RATED RUNNING CURRENT A 0.79 0.97
MOTOR OUTPUT W 60 100
POLES 6
COIL
TUBE
MATERIAL COPPER
DIAMETER mm 7
FIN
MATERIAL ALUMINIUM
FACE AREA m
2
0.461 0.464
ROW 3
AIR QUALITY FILTER
TYPE WASHABLE SARANET FILTER
QUANTITY pc 1
CASING COLOUR WITHOUT PAINT
OUTDOOR UNIT
AIR FLOW l/s / CFM 1605 / 3400
SOUND PRESSURE LEVEL dBA 58
UNIT DIMENSION HEIGHT X WIDTH X DEPTH mm 852 X 1030 X 400
PACKING DIMENSION HEIGHT X WIDTH X DEPTH mm 1010 X 1180 X 514
UNIT WEIGHT kg 100 100 105
PIPE
CONNECTION
TYPE FLARE VALVE
SIZE
LIQUID mm 9.52
GAS mm 19.05
FAN
TYPE PROPELLER
DRIVE DIRECT
FAN MOTOR
TYPE INDUCTION
INDEX OF PROTECTION (IP) IP54
INSULATION GRADE CLASS B
RATED INPUT POWER (R) W 257
RATED INPUT POWER (RY) W 276
RATED RUNNING CURRENT (R) A 1.10
RATED RUNNING CURRENT (RY) A 1.34
MOTOR OUTPUT W 145
POLES 8
COMPRESSOR
TYPE SCROLL
OIL TYPE MOBIL EAL MINERAL OIL
OIL AMOUNT cm
3
1951 1951 1950
R RATED INPUT POWER W 3017 3217 4122
RY
RATED INPUT POWER (COOLING) W 3148 3048 4303
RATED INPUT POWER (HEATING) W 2798 2748 3703
R RATED INPUT CURRENT A 14.81 5.50 7.31
RY
RATED INPUT CURRENT
(COOLING)
A 15.27 5.38 7.43
RATED INPUT CURRENT
(HEATING)
A 13.77 5.37 6.71
LOCKED ROTOR AMP. A 114 48 58
COIL
TUBE
MATERIAL COPPER
DIAMETER (R / RY) mm 9.52 / 7 7
FIN
MATERIAL ALUMINIUM
FACE AREA m
2
0.87
ROW 2
CASING COLOUR LIGHT GREY
ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151 (NON-DUCTED UNIT) OR ISO 13253 (DUCTED UNIT).
COOLING HEATING
INDOOR: 27°C DB/ 19°C WB INDOOR: 20°C DB
OUTDOOR: 35°C DB/ 24°C WB OUTDOOR: 7°C DB/ 6°C WB
