Daikin FTC50PRV16 - Fan Motor and Fan Rotor; Remove Side Plate and Fan Rotor Screw

Fan Motor / Fan Rotor Si041257EC
12 Removal Procedure
6. Fan Motor / Fan Rotor
Warning

Be sure to wait for 10 minutes or more after turning off all power supplies before
disassembling work.
Step Procedure Points
1 Remove the 2 screws,
and then the right side
plate.
2 Remove the screw of
the fan rotor.
Right side
plate
(R19801)
(R19802)
Fan rotor
