Daikin FTD20JEV1K - Outline and Dimensions

English
1
Indoor Unit
A
TOP VIEW
C
SIDE VIEW
B
THE MARK SHOWS PIPING DIRECTION
REAR REAR
RIGHTLEFT
BOTTOM BOTTOM
FRONT GRILLE FIXED SCREWS
(INSIDE)
LOUVER
SIGNAL
RECEIVER
INDOOR UNIT
ON/OFF SWITCH
ROOM TEMPERATURE
THERMISTOR (INSIDE)
NAME PLATE
TERMINAL
BLOCK
WITH EARTH
TERMINAL
All dimensions are in mm
Original Instruction
OUTLINE AND DIMENSIONS
D
B
G
HJ
L
M
A
K
F
I
G
F
E
Through the wall
hole Ø 65mm
Drain hose position
Liquid pipe end Gas pipe end
INSTALLATION PLATE FTD20/25JEV1K
All dimensions are in mm
Dimension
Model
ABCDE FGH I JKLM
FTD20/25JEV1K 1065 310 228 190 173 61 40 45 48 91 219 580 45
FRONT VIEW
 Recommended mounting plate retention
spots (7 spots in all)
