DAMA-SM-21-001 Specification Data
Specifications 17
1) ALL UNITS ARE BEING TESTED ACCORDING TO AHRI 210/240 STANDARD.
2) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
MODEL
INDOOR UNIT FTK18A FTK24A
OUTDOOR UNIT RK18A RK24A
Rated Capacity (Min. ~ Max.)
kW 5.28 (1.60 - 5.86) 6.21 (1.60 - 7.03)
Btu/h 18000 (5500 - 20000) 21200 (5500 - 24000)
Moisture Removal gal/h 0.41 0.67
Rated Running Current A 6.39 7.70
Rated Power Consumption W 1440 1738
EER Btu/h/W 12.5 12.2
SEER 18.5 19.0
Power Factor (Rated) N/A
Piping
Connections
Liquid inch (mm) 1/4” (6.35)
Gas inch (mm) 1/2” (12.70) 5/8” (15.88)
Refrigerant
Type R410A
Charge lbs (kg) 3.20 (1.45) 3.86 (1.75)
Max. Interunit Piping Length ft (m) 98-1/2 (30)
Max. Interunit Height Difference ft (m) 65-5/8 (20)
Chargeless ft (m) 32-13/16 (10)
Amount of Additional Charge of Refrigerant oz/ft (g/m) 0.21 (20)
INDOOR UNIT FTK18A FTK24A
Front Panel Colour WHITE
Airflow Rate
Turbo CFM 754
High CFM 716
Medium CFM 605
Low CFM 467
Quiet CFM 395
Sound Pressure Level (H/M/L/Q) dBA 49/44/38/33 53/45/39/34
Fan
Type CROSS FLOW
Drive DIRECT
Speed 3 STEPS, QUIET, AUTO, TURBO
Fan Motor
Type DIRECT CURRENT
Motor Output W 35
Running Current (Rated) A 0.145
Power Consumption (Rated) W 47
Air Direction Control UP, DOWN, LEFT, RIGHT
Air Filter CATECHIN
Dimensions (H X W X D) inch (mm) 11-11/16 X 39-1/2 X 11-1/3 (297 X 1005 X 288)
Packaged Dimensions (H X W X D) inch (mm) 14-1/4 X 42-1/4 X 14-1/8 (362 X 1073 X 358)
Weight lbs (kg) 31 (14)
Gross Weight lbs (kg) 38 (17)
Condensate Drain Size in. (mm) 3/4 (19.00)
OUTDOOR UNIT RK18A RK24A
Casing Colour IVORY WHITE
Airflow Rate High CFM 2005 1908
Sound Pressure Level dBA 54 55
Fan
Type PROPELLER
Drive DIRECT
Fan Motor
Type DIRECT CURRENT
Index of protection (IP) 23
Insulation Grade E
Running Current (Rated) A 0.99 1.00
Power Consumption (Rated) W 81 86
Motor Output W 128
Poles 8
Compressor
Type HERMETIC SWING
Model D1C128S8P20-PN
Oil type DAPHNE FVC50K
Oil amount oz (cm
3
) 21.5 (650)
Running Current (Rated) A 5.255 6.555
Power Consumption (Rated) W 1312 1605
Heat Exchanger Type FIN TUBE
Starting Current A 7.33 11.00
Dimensions (H X W X D) inch (mm) 27-13/32 x 36-5/8 x 13-13/16 (696 X 930 X 351)
Packaged Dimensions (H X W X D) inch (mm) 29-7/8 x 42-3/8 x 18-7/8 (760 X 1075 X 480)
Weight lbs (kg) 99 (45) 106 (48)
Gross Weight lbs (kg) 108 (49) 115 (52)
Drawing No. 3D128372 3D128372
Document No. (Set) 3D128372 3D128372
COOLING
INDOOR: 80°FDB (26.7°CDB) / 67°FWB (19.4°CWB)
OUTDOOR: 95°FDB (35°CDB)
