Daikin FTKD42GVM Service Manual

Si041143 Removal of Electrical Box / PCBs / Swing Motors
Removal Procedure 11
4
Disconnect the
connector [S49] from
the display PCB.
5
Unfasten the 4 hooks.
Remove the
INTELLIGENT EYE
sensor PCB, and
disconnect the
connector [S36].
6
Unfasten the 2 hooks.
Remove the signal
receiver PCB and
disconnect the
connector [S48].
Step
Procedure Points
(R11352)
[S49]
INTELLIGENT EYE
sensor PCB
(R11353)
[S36]
Signal receiver
PCB
(R11354)
[S48]
