Read Before Operation
 Open the front panel
Air  lter
Titanium apatite
photocatalytic
air-purifying  lter
Outdoor Unit
•Theappearanceoftheoutdoorunitmaydifferbetweendifferentmodels.
Refrigerant pipes and
inter-unit wire
Earth terminal (inside)
Drain hose
Air inlet
(back and side)
Air outlet
Outdoor temperature
sensor (back)
Model name plate
