SiENBE12-713 Specifications
Specifications 27
50Hz 230V
Model
FTXS50D2V1W FTXS50D2V1L
Cooling Heating Cooling Heating
Rated Capacity 5.0kW Class 5.0kW Class
Front Panel Color White White
Air Flow Rates
m³/min
(cfm)
H 11.4 (402) 11.4 (402) 11.4 (402) 11.4 (402)
M 9.3 (328) 9.4 (332) 9.3 (328) 9.4 (332)
L 7.1 (251) 7.4 (261) 7.1 (251) 7.4 (261)
SL 6.2 (219) 6.3 (222) 6.2 (219) 6.3 (222)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 40 40
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable-Washable-Mildew Proof Removable-Washable-Mildew Proof
Running Current (Rated) A 0.21 0.21 0.21 0.21
Power Consumption (Rated) W 48 48 48 48
Power Factor % 99.4 99.4 99.4 99.4
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 283×800×195 283×800×195
Packaged Dimensions (H×W×D) mm 265×855×340 265×855×340
Weight kg 9 9
Gross Weight kg 12 12
Operation
Sound
H/M/L/SL dBA 46/41/35/32 46/40/34/31 46/41/35/32 46/40/34/31
Sound Power H dBA 62 62 62 62
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ12.7 φ15.9
Drain mm
φ18.0 φ18.0
Drawing No. 3D051814 3D051815
Model
FTXS20CAVMB FTXS25CAVMB
Cooling Heating Cooling Heating
Rated Capacity 2.5kW Class 2.5kW Class
Front Panel Color White White
Air Flow Rates
m³/min
(cfm)
H 7.7 (272) 7.8 (275) 7.7 (272) 7.8 (275)
M 5.9 (208) 6.5 (230) 5.9 (208) 6.5 (230)
L 4.2 (148) 5.3 (187) 4.2 (148) 5.3 (187)
SL 3.6 (127) 4.6 (162) 3.6 (127) 4.6 (162)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 18 18
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable-Washable-Mildew Proof Removable-Washable-Mildew Proof
Running Current (Rated) A 0.18 0.18 0.18 0.18
Power Consumption (Rated) W 40 40 40 40
Power Factor % 96.6 96.6 96.6 96.6
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 273×784×195 273×784×195
Packaged Dimensions (H×W×D) mm 258×834×325 258×834×325
Weight kg 7.5 7.5
Gross Weight kg 11 11
Operation
Sound
H/M/L/SL dBA 38/32/25/22 38/33/28/25 38/32/25/22 38/33/28/25
Sound Power H dBA 56 56 56 56
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ 9.5 φ 9.5
Drain mm
φ18.0 φ18.0
Drawing No. 3D050941 3D050943
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
