Indoor Unit SiENBE04-507A
160 Removal Procedure
Step Procedure Points
2. Removing the horizontal
blade (small)
1
2
3
Remove the horizontal
blade (small) while
bending the fixed part
at the centre slightly.
Unfasten the left side.
Unfasten the key type
fixing shaft at the right
side.
Horizontal blade (small)
Key
