Fan Motor Si041251EC
16 Removal Procedure
5
Unfasten the hook (b)
and remove the fan
motor fixing plate.
6
Remove the fan motor.
Step Procedure Points
Hook (b)
(R20216)
(R4394)
Fan motor
