Installation Guideline
All dimensions are in mm
Indoor Unit FTV50/60P
Recommended mounting plate retention spots
(7 spots in all)
190
173
61
310
61
Gas pipe endLiquid pipe end
48
45
580
1065
219
40
40
91
45
Through the
wall hole
Ø 65mm
Drain hose
position
All dimensions are in mm
Indoor Unit FTV85PS
1289
310
5750
57
201 193
45
80
196
177
650 52
