Specication Data
Specication Data
FTV-A
MODEL
INDOOR UNIT FTV28A FTV35A FTV50A FTV60A
OUTDOOR UNIT RV28A RV35A RV50A RV60A
Rated Capacity
kW 2.78 3.66 5.28 7.03
Btu/h 9,500 12,500 18,000 24,000
Rated Running Current A 3.76 4.77 7.35 9.88
Rated Power Consumption W 840 1,075 1,650 2,220
EER W/W 3.31 3.41 3.20 3.17
CSPF Wh/Wh 3.52 3.62 3.40 3.36
Power Factor (Rated) 0.971 0.980 0.976 0.977
Piping
Connections
Liquid mm 6.35
Gas mm 9.52 12.70
Refrigerant
Type R32
Charge kg 0.50 0.68 1.10 1.10
Max. Interunit Piping Length m 25 30
Max. Interunit Height Difference m 15 20
INDOOR UNIT FTV28A FTV35A FTV50A FTV60A
Front Panel Colour WHITE
Airow Rate
Turbo CFM 410 650 580 800
High CFM 380 410 425 690
Medium CFM 310 320 350 605
Low CFM 270 300 305 545
Quiet CFM 240 240 280 500
Sound Pressure Level (H/M/L/Q) dBA 38/33/30/28 40/35/33/28 42/38/35/33 44/41/39/37
Fan
Type CROSS FLOW
Drive DIRECT
Fan Motor
Type 1-PHASE SCR
Motor Output W 21 21 21 35
Running Current (Rated) A 0.20 0.20 0.20 0.36
Power Consumption (Rated) W 37 42 44 77
Air Direction Control UP , DOWN, LEFT, RIGHT
Air Filter GREEN TEA
Dimensions (H x W x D) mm 288 x 770 x 234 297 x 990 x 273
Packaged Dimensions (H x W x D) mm 327 x 830 x 363 371 x 1,073 x 375
Weight kg 9.0 9.0 9.5 13.0
Condensate Drain Size mm 19.05
OUTDOOR UNIT RV28A RV35A RV50A RV60A
Casing Colour IVORY WHITE
Airow Rate CFM 927 827 1,400 1,400
Sound Pressure Level dBA 46 48 49 52
Fan
Type PROPELLER
Drive DIRECT
Fan Motor
Type 1-PHASE FIXED SPEED
Index of protection (IP) 23 44
Insulation Grade B F
Running Current (Rated) A 0.22 0.23 0.41 0.41
Power Consumption (Rated) W 50 51 92 92
Motor Output W 20 60
Poles 6
Compressor
Type ROTARY
Oil type FW50S
DAPHNE
FW68DA
RM-LP56EG or
equivalent
RM-LP56EG /
RmM68EA or
equivalent
Oil amount cm
3
300 270 450 570
Running Current (Rated) A 3.34 4.34 6.74 9.11
Power Consumption (Rated) W 753 982 1,514 2,051
Heat Exchanger Type FIN TUBE
Dimensions (H x W x D) mm 550 x 658 x 273 615 x 845 x 300
Packaged Dimensions (H x W x D) mm 580 x 775 x 355 679 x 992 x 414
Weight kg 25 28 42 46
1) ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151 (NON-DUCTED UNIT) OR ISO 13253 (DUCTED UNIT).
2) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
Cooling
INDOOR: 27°CDB / 19°CWB
OUTDOOR: 35°CDB
