Specication Data
FTV-P
MODEL
INDOOR UNIT FTV28P FTV35P FTV50P FTV60P
OUTDOOR UNIT RV28F RV35F RV50C RV60C
Rated Capacity
kW 2.78 3.52 5.28 6.45
Btu/h 9,500 12,000 18,000 22,000
Rated Running Current A 3.86 5.03 8.12 9.76
Rated Power Consumption W 865 1,135 1,835 2,215
EER W/W 3.22 3.10 2.87 2.91
CSPF Wh/Wh 3.42 3.29 3.05 3.09
Power Factor (Rated) 0.978 0.981 0.982 0.986
Piping
Connections
Liquid mm 6.35
Gas mm 9.52 12.70
Refrigerant
Type R32
Charge kg 0.50 0.76 0.75 0.70
Max. Interunit Piping Length m 25 30
Max. Interunit Height Difference m 15
INDOOR UNIT
FTV28P FTV35P FTV50P FTV60P
Front Panel Colour WHITE
Airow Rate
Turbo CFM 358 372 594 641
High CFM 342 355 531 614
Medium CFM 282 298 474 537
Low CFM 225 242 422 474
Quiet CFM 209 225 381 418
Sound Pressure Level (H/M/L/Q) dBA 37/33/27/25 39/35/29/28 42/39/36/35 46/43/39/37
Fan
Type CROSS FLOW
Drive DIRECT
Fan Motor
Type 1-PHASE SCR
Motor Output W 18 18 26 30
Running Current (Rated) A 0.19 0.21 0.30 0.34
Power Consumption (Rated) W 37 42 61 72
Air Direction Control UP & DOWN
Air Filter SARANET
Dimensions (H x W x D) mm 288 X 800 X 212 310 X 1,065 X 228
Packaged Dimensions (H x W x D) mm 344 X 874 X 274 386 X 1,136 X 314
Weight kg 9.0 9.0 14.0 14.0
Condensate Drain Size mm 19.05
OUTDOOR UNIT
RV28F RV35F RV50C RV60C
Casing Colour IVORY WHITE
Airow Rate CFM 927 827 1,430 1,590
Sound Pressure Level dBA 46 48 51 52
Fan
Type PROPELLER
Drive DIRECT
Fan Motor
Type 1-PHASE FIXED SPEED
Index of protection (IP) 23
Insulation Grade B F
Running Current (Rated) A 0.22 0.23 0.34 0.53
Power Consumption (Rated) W 50 51 78 121
Motor Output W 20 20 32 60
Poles 6
Compressor
Type ROTARY
Oil type
FW50S DAPHNE FW68DA FW50S
Oil amount cm
3
350 270 670 670
Running Current (Rated) A 3.45 4.59 7.48 8.89
Power Consumption (Rated) W 778 1,042 1,696 2,022
Heat Exchanger Type FIN TUBE
MICRO
CHANNEL
Dimensions (H x W x D) mm 550 X 658 X 273 654 X 855 X 328
Packaged Dimensions (H x W x D) mm 580 X 775 X 355 693 X 990 X 415
Weight kg 25 28 41
ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151 (NON-DUCTED UNIT) OR ISO 13253 (DUCTED UNIT).
Cooling
INDOOR: 27°CDB / 19°CWB
OUTDOOR: 35°CDB
