Daikin FTV-P Series User Manual

11
Installation Guideline
All dimensions are in mm
Indoor Unit FTV28/35P
Gas pipe end
Liquid pipe end
Through the
wall hole
Ø 65mm
Drain hose
position
(5 spots in all)
141401
30
46
56181
800
55 207 52
153
46
30
288
Recommended mounting plate retention spots
All dimensions are in mm
Indoor Unit FTV60A
Ç Recommended mounting plate
retention spots (7 spots in all)
Use a tape measure as shown.
Position the end of the tape
measure at w
Through-the-wall
hole Ø 65mm
251.645.4
Drain hose position
unit : mm
Place a leveler
on these tabs.
06071
990
49.5
117
Ø 65
126.5
251.645.4
65.5
170
Ø 65
