Si18-201 Specifications
Specifications 21
Refer to Engineering Data Book.
"
7.1kW Class
50Hz 220-230-240V / 60Hz 220-230V
Model FTKD71JVE FTKD71JVEA
Rating Capacity kW 7.1
Front Panel Color Almond White
Air Flow Rates
m³/min
H 14.3
M 12.3
L 10.4
cfm
H 505
M 434
L 367
Fan
Type Cross Flow Fan
Motor Output W 54
Speed Steps 5 Steps and Auto
Air Filter Removal / Washable / Mildew Proof
Running Current
(Rated) A 0.23-0.22-0.21 / 0.23-0.22
Power Consumption
(Rated) W 50
Power Factor
% 98.8-98.8-99.2 / 98.8-98.8
Temperature Control Microcomputer Control
Dimensions (H×W×D) mm 298×1,050×190
Package Dimensions (W×D×H) mm 1,183×367×289
Weight kg 12
Gross Weight kg 16
Operation Sound dBA
H46
M42
L37
Heat Insulation Both Liquid and Gas Pipes
Piping
Connection
Liquid mm
φ
9.5
Gas mm
φ
15.9
Drain mm
φ
18.0
Drawing No. 3D027865A 3D027862
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
