Specifications Si18-201
36 Specifications
"
Floor / Ceiling Suspended Dual Type
★
Refer to Engineering Data Book.
50Hz 220V
Model FLK25HVEC FLK35HVEC
Rating Capacity kW 2.5 3.5
Front Panel Color Almond White Almond White
Air Flow Rates
m³/min
H7.6 8.7
M6.8 7.7
L6.0 6.6
cfm
H 268 307
M 240 270
L 212 233
Fan
Type Sirocco Fan Sirocco Fan
Motor Output W 34 34
Speed Steps 5 Steps and Auto 5 Steps and Auto
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current
★
(Rated) A 0.32 0.36
Power Consumption
★
(Rated) W 68 76
Power Factor
★
% 96.6 96.0
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 490×1,050×200 490×1,050×200
Package Dimensions mm 1,100×566×284 1,100×566×284
Weight kg 16 16
Gross Weight kg 23 23
Operation Sound dBA
H37 38
M34 35
L31 32
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping
Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
9.5
φ
12.7
Drain mm
φ
18.0
φ
18.0
Drawing No. 3D025001 3D025002
50Hz 220V
Model FLK50HVEC FLK60HVEC
Rating Capacity kW 5.0 5.7
Front Panel Color Almond White Almond White
Air Flow Rates
m³/min
H 11.4 12.0
M 10.0 10.7
L8.5 9.3
cfm
H 402 424
M 351 376
L 300 328
Fan
Type Sirocco Fan Sirocco Fan
Motor Output W 34 34
Speed Steps 5 Steps and Auto 5 Steps and Auto
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current
★
(Rated) A 0.45 0.47
Power Consumption
★
(Rated) W 94 96
Power Factor
★
% 94.2 92.8
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 490×1,050×200 490×1,050×200
Package Dimensions mm 1,100×566×284 1,100×566×284
Weight kg 17 17
Gross Weight kg 24 24
Operation Sound dBA
H47 49
M43 45
L39 41
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping
Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
12.7
φ
15.9
Drain mm
φ
18.0
φ
18.0
Drawing No. 3D025003 3D025004
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
