Read Before Operation
 Open the front panel
Outdoor Unit
• The appearance of the outdoor unit may differ between different models.
Refrigerant piping and inter-
unit wiring
Drain hose
Air outlet
Model name plate
Earth terminal (inside)
Air inlet
(back and side)
Outdoor temperature
sensor (back)
Names of Parts
■ FTX50K2V1B / FTX60K2V1B / FTX71K2V1B
■ FTXP50K3V1B / FTXP60K3V1B / FTXP71K3V1B
Air fi lter
Titanium apatite deodorizing
fi lter (with frame)
Model name
plate
