Daikin FTXS20D3VMW - Page 302

SiENBE12-713 Outdoor Unit
Removal Procedure 291
10
Loosen the 4 screws of
the discharge grille.
11
Loosen the 2 screws of
the stop valve cover.
And then slide the
cover downward to
remove.
" When assembling, make
sure to catch the 5 hooks.
Step
Procedure Points
Stop valve cover
