Performance Data
Model: FTY20JXV1 - RY20CXV1
Cooling Mode
AFR
(CFM)
EWB EDB
Outdoor temperature
19°C 25°C 30°C 35°C 40°C 46°C
TC SC PI TC SC PI TC SC PI TC SC PI TC SC PI TC SC PI
424
16°C
21°C 5.39 3.71 1.41 5.20 3.61 1.52 5.01 3.52 1.65 4.81 3.42 1.79 4.42 3.18 1.94 4.08 2.99 2.14
24°C 5.40 4.44 1.41 5.21 4.34 1.52 5.02 4.24 1.65 4.82 4.13 1.79 4.42 3.86 1.94 4.09 3.64 2.14
27°C 5.44 5.04 1.41 5.26 4.92 1.52 5.08 4.81 1.65 4.89 4.68 1.79 4.51 4.36 1.94 4.19 4.09 2.15
30°C 5.61 5.61 1.42 5.45 5.45 1.53 5.28 5.28 1.66 5.11 5.11 1.81 4.74 4.74 1.96 4.44 4.44 2.17
19°C
24°C 5.95 3.46 1.43 5.74 3.38 1.55 5.53 3.29 1.68 5.31 3.19 1.82 4.88 2.97 1.97 4.51 2.80 2.17
27°C 5.95 3.96 1.43 5.74 3.87 1.55 5.53 3.79 1.68 5.32 3.69 1.82 4.89 3.45 1.97 4.52 3.27 2.17
30°C 5.96 4.89 1.43 5.76 4.79 1.55 5.55 4.68 1.68 5.34 4.57 1.82 4.92 4.27 1.97 4.56 4.04 2.18
33°C 6.03 6.03 1.43 5.84 5.84 1.55 5.65 5.65 1.68 5.46 5.46 1.83 5.05 5.05 1.98 4.72 4.72 2.19
22°C
27°C 6.55 3.39 1.45 6.32 3.31 1.58 6.09 3.23 1.71 5.85 3.14 1.85 5.38 2.92 2.01 4.98 2.76 2.21
30°C 6.55 4.13 1.45 6.32 4.04 1.58 6.09 3.95 1.71 5.85 3.86 1.85 5.38 3.61 2.01 4.98 3.42 2.22
33°C 6.55 4.83 1.45 6.32 4.73 1.58 6.09 4.64 1.71 5.86 4.54 1.85 5.39 4.27 2.01 4.99 4.05 2.22
36°C 6.57 5.47 1.46 6.36 5.36 1.58 6.13 5.25 1.71 5.91 5.13 1.86 5.45 4.81 2.02 5.07 4.57 2.22
478
16°C
21°C 5.61 3.87 1.42 5.41 3.77 1.53 5.20 3.67 1.66 4.99 3.57 1.80 4.58 3.32 1.95 4.23 3.12 2.15
24°C 5.63 4.70 1.42 5.43 4.59 1.54 5.22 4.48 1.66 5.01 4.36 1.80 4.60 4.07 1.96 4.26 3.84 2.16
27°C 5.70 5.33 1.42 5.51 5.21 1.54 5.32 5.08 1.67 5.12 4.92 1.81 4.73 4.57 1.97 4.41 4.28 2.17
30°C 5.93 5.93 1.43 5.76 5.76 1.55 5.59 5.59 1.68 5.41 5.41 1.83 5.01 5.01 1.99 4.68 4.68 2.19
19°C
24°C 6.18 3.66 1.44 5.96 3.57 1.56 5.74 3.47 1.69 5.51 3.38 1.83 5.06 3.15 1.99 4.67 2.97 2.19
27°C 6.19 4.22 1.44 5.97 4.12 1.56 5.75 4.03 1.69 5.52 3.93 1.83 5.07 3.68 1.99 4.69 3.48 2.19
30°C 6.22 5.20 1.44 6.01 5.09 1.56 5.79 4.97 1.69 5.57 4.85 1.84 5.13 4.54 1.99 4.76 4.29 2.20
33°C 6.33 6.33 1.45 6.13 6.13 1.57 5.94 5.94 1.70 5.74 5.74 1.85 5.32 5.32 2.01 4.97 4.97 2.22
22°C
27°C 6.79 3.58 1.47 6.55 3.50 1.59 6.31 3.41 1.72 6.06 3.32 1.87 5.57 3.10 2.03 5.15 2.92 2.23
30°C 6.80 4.40 1.47 6.56 4.31 1.59 6.32 4.21 1.73 6.07 4.11 1.87 5.58 3.85 2.03 5.16 3.65 2.24
33°C 6.81 5.15 1.47 6.58 5.05 1.59 6.34 4.95 1.73 6.09 4.85 1.87 5.60 4.55 2.03 5.19 4.32 2.24
36°C 6.86 5.82 1.47 6.63 5.71 1.60 6.40 5.60 1.73 6.17 5.47 1.88 5.69 5.11 2.04 5.31 4.82 2.25
536
16°C
21°C 5.82 4.04 1.43 5.61 3.93 1.55 5.39 3.83 1.68 5.17 3.72 1.82 4.74 3.47 1.97 4.37 3.26 2.17
24°C 5.85 4.90 1.43 5.64 4.79 1.55 5.43 4.67 1.68 5.21 4.55 1.82 4.78 4.24 1.97 4.42 4.00 2.17
27°C 5.94 5.62 1.44 5.75 5.48 1.55 5.56 5.32 1.68 5.36 5.16 1.83 4.95 4.78 1.99 4.61 4.46 2.19
30°C 6.24 6.24 1.45 6.06 6.06 1.57 5.87 5.87 1.70 5.68 5.68 1.85 5.26 5.26 2.01 4.91 4.91 2.22
19°C
24°C 6.41 3.87 1.45 6.17 3.78 1.57 5.94 3.68 1.71 5.70 3.58 1.85 5.23 3.34 2.01 4.83 3.15 2.21
27°C 6.42 4.48 1.46 6.19 4.38 1.58 5.96 4.27 1.71 5.72 4.17 1.85 5.25 3.90 2.01 4.85 3.69 2.21
30°C 6.48 5.51 1.46 6.25 5.39 1.58 6.02 5.27 1.71 5.79 5.14 1.86 5.33 4.80 2.01 4.95 4.52 2.22
33°C 6.62 6.62 1.46 6.42 6.42 1.59 6.23 6.23 1.72 6.02 6.02 1.87 5.58 5.58 2.03 5.22 5.22 2.24
22°C
27°C 7.03 3.79 1.48 6.78 3.70 1.61 6.52 3.61 1.74 6.26 3.52 1.89 5.75 3.28 2.05 5.32 3.10 2.25
30°C 7.04 4.67 1.48 6.79 4.58 1.61 6.54 4.48 1.74 6.27 4.38 1.89 5.76 4.10 2.05 5.33 3.89 2.25
33°C 7.07 5.47 1.48 6.82 5.38 1.61 6.57 5.26 1.74 6.31 5.15 1.89 5.81 4.82 2.05 5.38 4.58 2.26
36°C 7.13 6.18 1.49 6.91 6.07 1.61 6.67 5.93 1.75 6.43 5.79 1.90 5.94 5.40 2.06 5.54 5.08 2.27
Model: FTY20JXV1 - RY20CXV1
Heating Mode
ID DB
Outdoor WB
-9°C -6°C -5°C 6°C 12°C 15°C 18°C
TC (kW) SC (kW) TC (kW) SC (kW) TC (kW) SC (kW) TC (kW) SC (kW) TC (kW) SC (kW) TC (kW) SC (kW) TC (kW) SC (kW)
15°C 3.544 3.544 4.011 4.011 4.166 4.166 5.879 5.879 6.813 6.813 7.281 7.281 7.748 7.748
17°C 3.451 3.451 3.825 3.825 4.065 4.065 5.872 5.872 6.678 6.678 7.138 7.138 7.599 7.599
19°C 3.358 3.358 3.639 3.639 3.964 3.964 5.865 5.865 6.542 6.542 6.996 6.996 7.451 7.451
21°C 3.265 3.265 3.528 3.528 3.863 3.863 5.758 5.758 6.406 6.406 6.854 6.854 7.303 7.303
23°C 3.172 3.172 3.491 3.491 3.762 3.762 5.551 5.551 6.270 6.270 6.712 6.712 7.155 7.155
25°C 3.079 3.079 3.454 3.454 3.661 3.661 5.344 5.344 6.134 6.134 6.570 6.570 7.006 7.006
27°C 2.986 2.986 3.416 3.416 3.560 3.560 5.137 5.137 5.998 5.998 6.428 6.428 6.858 6.858
Frost Region
Remark:
AFR: Air fl ow rate (CFM)
EWB: Entering Wet Bulb Temp. (°C)
EDB: Entering Dry Bulb Temp. (°C)
TC: Total Cooling / Heating Capacity (kW)
SC: Sensible Cooling / Heating Capacity (kW)
PI: Power Input (kW)
Notes:
1. Ratings shown are net capacities.
2. shows nominal capacities.
3. Direct interpolation is permissible. Do not extrapolate.
4. Unit is able to operate at ambient from 19°C to 46°C DB (cooling) / -9°C to 18°C WB (heating) without pressure trip.
