English
1-3
B
A
Q
P
RS
D
O
KLL
M
N
FE
C
G
H
IJ
All dimensions are in mm
Outdoor Unit
Dimension
Model
ABCDEFGH I JKLMNO
RYN50LV1B 855 628 328 520 179 46 93 149 101 113 603 126 164 15 34
RYN60LV1B 855 730 328 520 179 46 93 149 101 113 603 126 164 15 34
Dimension
Model
PQRS
RYN50LV1B 23 362 73 75
RYN60LV1B 23 362 73 75
N
