Outlines & Dimensions
68
Model: UAHMM30/40A (Vertical Air Discharge)
MODEL
A
UAHMM30AY1/
UAHMM30AZY1
132.0
UAHMM40AY1/
UAHMM40AZY1
155.0
WATER OUTLET
WATER INLET
SEE DETAIL A
754.6
88.0
47.7
50.0
117.0
47.7
20.0
60.0
453.5174.0
35.0
945.0
20.0
533.0
474.0
533.0
1600.0
1640.0
1540.0
60.0
408.0
382.0
50.0
53.0
1370.0
1540.0
SEE DETAIL A
SEE DETAIL B
980.0
850.0
130.0
88.0
A
103.0
747.0 35.0
SEE DETAIL B
257.5
174.0
A
885.0
Note: Dimension in mm
