Wiring Diagrams
Molde: FWW 800-1400
H
M
L
FAN SPEED SWITCH
HF
MF
N
(220V~ /50Hz)
YELLOW
BROWN
ORANGE
YELLOW
BROWN
ORANGE
BLUE
BLACK
BLACK
BLACK
BLACK
BLUE
MOTOR
CAPACITOR
MOTOR
CAPACITOR
FAN
MOTOR
1
FAN
MOTOR
2
Only unit 800~1200 have fan motor2
NOTE:
HF: FAN SPEED HIGH
MF: FAN SPEED MEDIUM
LF: FAN SPEED LOW
— — — — — FIELD WIRING
LF
L
