Daikin FWW200 - Sound Data

6
NOTES:
ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
Components Data
FWW-VC
FWW200VC FWW300VC FWW400VC FWW500VC FWW600VC FWW700VC FWW800VC FWW1000VC FWW1200VC FWW1400VC
FAN
TYPE GALVANIZED STEEL DOUBLE STAGE IMPELLER CENTRIFUGAL (BLADE: FORWARD)
QUANTITY 1 2 2 2 2 2 3 3 4 4
MATERIAL GALVANIZED STEEL
DRIVE DIRECT DRIVE
DIAMETER
mm 150
in 5.904
LENGTH
mm 150/200/240
in 5.91/7.87/9.45
MOTOR
TYPE SINGLE PHAZE BALL BEARING CAPACITOR RUNNING
QUANTITY 1 1 1 1 1 1 2 2 2 2
IP/INSULATION GRADE IP20/B
COIL
TUBE
MATERIAL COPPER
DIAMETER
mm 7
in 0.28
THICKNESS
mm 0.25
in 0.01
FIN
MATERIAL HYDROPHILIC ALUMINUM
THICKNESS
mm 0.11
in 0.0043
FACE AREA
m
2
0.08 0.12 0.13 0.15 0.17 0.18 0.25 0.26 0.30 0.34
ft
2
0.86 1.29 1.40 1.61 1.83 1.94 2.69 2.80 3.23 3.66
ROW 3
FIN PER INCH 17
AIR
FILTER
(Option)
TYPE NYLON/ALUMINIUM FRAME
SIZE
LENGTH
mm 438 628 678 758 858 908 1238 1288 1488 1638
in 17.24 24.72 26.69 29.83 33.77 35.74 48.73 50.70 58.57 64.47
WIDTH
mm 196
in 7.71
THICKNESS
mm 8
in 0.31
NOTES:
1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
2) SOUND PRESSURE LEVEL ARE ACCORDING TO MICROPHONE POSITION OF THE MEASUREMENT POINT IS 1m
IN FRONT AND 1m BELOW THE UNIT.
Sound Data
FWW-VC
Model FWW200VC FWW300VC FWW400VC FWW500VC FWW600VC FWW700VC FWW800VC FWW1000VC FWW1200VC FWW1400VC
Sound
Pressure Level
(ESP: 12Pa)
High dBA 33.9 33.2 40.0 40.3 44.4 45.2 43.9 47.9 48.0 51.0
Middle dBA 29.3 28.8 35.5 36.3 39 40.3 38.6 43.6 44.3 47.5
Low dBA 20.1 24.2 24.0 25.6 29.8 27.9 27.4 32.6 33.4 38.0
Sound
Pressure Level
(ESP: 30 Pa)
High dBA 37.3 37.6 41.6 44.3 46.5 46.6 46.2 49.3 50.9 52.0
Middle dBA 32.5 32.5 36.5 39.5 41.1 41.8 41.3 44.9 45.7 46.0
Low dBA 20.9 22.8 25.8 27.3 27.3 29.4 30.6 36.4 34.7 35.5
Sound
Pressure Level
(ESP: 50 Pa)
High dBA 41.2 42.2 44.4 46.4 47.5 47.5 48.3 50.6 51.8 53.5
Middle dBA 37.3 35.8 40.5 42.7 43.9 43.6 43.7 46.4 47.1 49.0
Low dBA 26.1 25.8 32.3 31.3 33.9 37.3 31.8 37.6 41.7 41.0
