•VRV
®
Systems • Indoor Units
10
• Indoor Units • Ceiling Suspended Unit • FXHQ-MAVE
7 Piping diagram
3
1
7
FXHQ-MA
4D034245A
Gas pipe
connection port
Liquid pipe
connection port
Filter
Filter
Electronic
expansion valve
Heat exchanger
Fan
