Daikin FXHQ63MAVE - 5 Capacity Tables; Cooling Capacity Tables

•VRV
®
Systems • Indoor Units
6
• Indoor Units • Ceiling Suspended Unit • FXHQ-MAVE
5 Capacity tables
5 - 1 Cooling capacity tables
3
1
5
FXHQ-MA
CA03A095
TC: Total capacity;kW – SHC: Sensible capacity;kW
Unit size
Nominal
capacity
Outdoor
air temp.
Indoor air temperature
14.0WB 16.0WB 18.0WB 19.0WB 20.0WB 22.0WB 24.0WB
20.0DB 23.0DB 26.0DB 27.0DB 28.0DB 30.0DB 32.0DB
CDBTCSHCTCSHCTCSHCTCSHCTCSHCTCSHCTCSHC
32 3.6 10.0 2.4 2.3 2.9 2.6 3.4 2.8 3.6 2.9 3.8 2.9 4.3 3.0 4.7 3.1
12.0 2.4 2.3 2.9 2.6 3.4 2.8 3.6 2.9 3.8 2.9 4.3 3.0 4.7 3.0
14.0 2.4 2.3 2.9 2.6 3.4 2.8 3.6 2.9 3.8 2.9 4.3 3.0 4.6 3.0
16.0 2.4 2.3 2.9 2.6 3.4 2.8 3.6 2.9 3.8 2.9 4.3 3.0 4.6 3.0
18.0 2.4 2.3 2.9 2.6 3.4 2.8 3.6 2.9 3.8 2.9 4.3 3.0 4.5 2.9
20.0 2.4 2.3 2.9 2.6 3.4 2.8 3.6 2.9 3.8 2.9 4.3 3.0 4.4 2.9
21.0 2.4 2.3 2.9 2.6 3.4 2.8 3.6 2.9 3.8 2.9 4.3 3.0 4.4 2.9
23.0 2.4 2.3 2.9 2.6 3.4 2.8 3.6 2.9 3.8 2.9 4.2 3.0 4.3 2.8
25.0 2.4 2.3 2.9 2.6 3.4 2.8 3.6 2.9 3.8 2.9 4.2 2.9 4.3 2.8
27.0 2.4 2.3 2.9 2.6 3.4 2.8 3.6 2.9 3.8 2.9 4.1 2.9 4.2 2.8
29.0 2.4 2.3 2.9 2.6 3.4 2.8 3.6 2.9 3.8 2.9 4.1 2.9 4.2 2.7
31.0 2.4 2.3 2.9 2.6 3.4 2.8 3.6 2.9 3.8 2.9 4.0 2.8 4.1 2.7
33.0 2.4 2.3 2.9 2.6 3.4 2.8 3.6 2.9 3.8 2.9 3.9 2.8 4.0 2.7
35.0 2.4 2.3 2.9 2.6 3.4 2.8
3.62.93.82.93.92.84.02.7
37.0 2.4 2.3 2.9 2.6 3.4 2.8 3.6 2.9 3.7 2.9 3.8 2.8 3.9 2.7
39.0 2.4 2.3 2.9 2.6 3.4 2.8 3.6 2.9 3.7 2.9 3.8 2.7 3.8 2.6
63 7.1 10.0 4.8 4.1 5.7 4.6 6.6 5.1 7.1 5.2 7.6 5.3 8.5 5.5 9.3 5.6
12.0 4.8 4.1 5.7 4.6 6.6 5.1 7.1 5.2 7.6 5.3 8.5 5.5 9.2 5.5
14.0 4.8 4.1 5.7 4.6 6.6 5.1 7.1 5.2 7.6 5.3 8.5 5.5 9.1 5.4
16.0 4.8 4.1 5.7 4.6 6.6 5.1 7.1 5.2 7.6 5.3 8.5 5.5 9.0 5.3
18.0 4.8 4.1 5.7 4.6 6.6 5.1 7.1 5.2 7.6 5.3 8.5 5.5 8.8 5.3
20.0 4.8 4.1 5.7 4.6 6.6 5.1 7.1 5.2 7.6 5.3 8.5 5.5 8.7 5.2
21.0 4.8 4.1 5.7 4.6 6.6 5.1 7.1 5.2 7.6 5.3 8.5 5.5 8.7 5.2
23.0 4.8 4.1 5.7 4.6 6.6 5.1 7.1 5.2 7.6 5.3 8.4 5.4 8.5 5.1
25.0 4.8 4.1 5.7 4.6 6.6 5.1 7.1 5.2 7.6 5.3 8.3 5.4 8.4 5.1
27.0 4.8 4.1 5.7 4.6 6.6 5.1 7.1 5.2 7.6 5.3 8.1 5.3 8.3 5.0
29.0 4.8 4.1 5.7 4.6 6.6 5.1 7.1 5.2 7.6 5.3 8.0 5.2 8.2 5.0
31.0 4.8 4.1 5.7 4.6 6.6 5.1 7.1 5.2 7.6 5.3 7.9 5.1 8.1 4.9
33.0 4.8 4.1 5.7 4.6 6.6 5.1 7.1 5.2 7.6 5.3 7.8 5.1 7.9 4.9
35.0 4.8 4.1 5.7 4.6 6.6 5.1
7.15.27.55.37.75.17.84.8
37.0 4.8 4.1 5.7 4.6 6.6 5.1 7.1 5.2 7.4 5.2 7.5 5.0 7.7 4.8
39.0 4.8 4.1 5.7 4.6 6.6 5.1 7.1 5.2 7.2 5.1 7.4 5.0 7.6 4.7
100 11.2 10.0 7.6 6.2 9.0 6.9 10.5 7.8 11.2 8.0 11.9 8.1 13.4 8.5 14.7 8.7
12.0 7.6 6.2 9.0 6.9 10.5 7.8 11.2 8.0 11.9 8.1 13.4 8.5 14.5 8.5
14.0 7.6 6.2 9.0 6.9 10.5 7.8 11.2 8.0 11.9 8.1 13.4 8.5 14.4 8.4
16.0 7.6 6.2 9.0 6.9 10.5 7.8 11.2 8.0 11.9 8.1 13.4 8.5 14.2 8.3
18.0 7.6 6.2 9.0 6.9 10.5 7.8 11.2 8.0 11.9 8.1 13.4 8.5 14.0 8.2
20.0 7.6 6.2 9.0 6.9 10.5 7.8 11.2 8.0 11.9 8.1 13.4 8.5 13.8 8.1
21.0 7.6 6.2 9.0 6.9 10.5 7.8 11.2 8.0 11.9 8.1 13.4 8.5 13.7 8.0
23.0 7.6 6.2 9.0 6.9 10.5 7.8 11.2 8.0 11.9 8.1 13.2 8.3 13.5 7.9
25.0 7.6 6.2 9.0 6.9 10.5 7.8 11.2 8.0 11.9 8.1 13.0 8.2 13.3 7.8
27.0 7.6 6.2 9.0 6.9 10.5 7.8 11.2 8.0 11.9 8.1 12.8 8.1 13.1 7.7
29.0 7.6 6.2 9.0 6.9 10.5 7.8 11.2 8.0 11.9 8.1 12.6 8.0 12.9 7.6
31.0 7.6 6.2 9.0 6.9 10.5 7.8 11.2 8.0 11.9 8.1 12.4 7.9 12.7 7.6
33.0 7.6 6.2 9.0 6.9 10.5 7.8 11.2 8.0 11.9 8.1 12.2 7.8 12.5 7.5
35.0 7.6 6.2 9.0 6.9 10.5 7.8
11.2 8.0 11.8 8.1 12.1 7.7 12.3 7.4
37.0 7.6 6.2 9.0 6.9 10.5 7.8 11.2 8.0 11.6 8.0 11.9 7.7 12.2 7.3
39.0 7.6 6.2 9.0 6.9 10.5 7.8 11.2 8.0 11.4 7.9 11.7 7.6 12.0 7.2
