Daikin FXSQ-A - 2. Wired Remote Controller BRC2;3 E52

ESIE15-11A | Part 3. Field settings 2. Wired remote controller BRC2/3E52
Page 22 23/09/16
VRV4 indoor units
2. Wired remote controller BRC2/3E52
2.1. Access field settings
To enable the Menu/Enter and Cancel button (these are default disabled on these controllers) in the Basic screen, proceed as
follow:
1. Keep the  button pressed.
2. Push the 3 indicated keys simultaneously while keeping the  button pressed.
To disable the Menu/Enter and Cancel button in the Basic screen, follow the same procedure.
1. Enable the Menu/Enter and Cancel
button. To enable, refer to page 22.
2. Press and hold the Cancel button for
4 seconds or longer. The Service
Settings menu is displayed.
BRC2E52 BRC3E52
2
2
2
2
1
Press and hold the Cancel button
for 4 seconds or longer while the
backlight is lit.
<Basic screen>
2.
