ESIE15-11A | Part 3. Field settings 4. Wired remote controller BRC1E51
23/09/16 Page 33
VRV4 indoor units
1b 4 error code detail 01 without details ex. E3
02 with details in field set &
service mode
ex. E3-04
03 with details in basic mode ex. E3-04
04
details in screen 'error
code' and 'main screen'
ex. E3-04
7 Display of symbol for defrost/hot start 01
on
02 off
8 automatic changeover winter-
time-summertime
01 not active
02
automatic
03 manual
04 according to centralized
control
a OFF-reminder timer 01 not visible
02
visible
1c 0 display of actual room temperature 01 off
02
on
1 selection air thermistor shown in room
temp display
01 air return (R1T) For auto-function & setback
02
thermistor of BRC1E
2 Selection mode display in auto mode 01 off Whether or not 'heating/cooling’ is dis-
played during automatic mode (other-
wise only 'automatic' is mentioned on
remocon)
02
on
3 Permission level setting 01
level 2 (low, high; on/off;
operation mode)
02 level 3 (on/off)
4 backlight on 01 permanently off
02
on for 30 seconds when
pushing any button
03 always on
5 operation when backlight is off 01
no when pushing a button, first backlight
is activated, function of button is not
activated
02 yes when pushing a button, backlight is
activated and immediately function of
button is activated
6 display of remocon 01
permanent display the screen always shows values
02 screen goes blank after 5
minutes
touching any button will reactivate the
screen
A Setback cooling differential 01 - Home leave function requires that
room temperature doesn't rise above
a certain temperature when there is
nobody home. If ambient temperature
rises above 34°C, cooling will auto-
matically start until 29°C (default dif-
ferential of 5°C) is reached, then unit
goes back to its original state.
02 -2°C
03 -3°C
04 -4°C
05
-5°C
06 -6°C
07 -7°C
08 -8°C
09 -9°C
B Setback heating differential 01 - Home leave function requires that
room temperature doesn't drop below
a certain temperature when there is
nobody home. If ambient temperature
drops below 14°C, heating will auto-
matically start until 19°C (default dif-
ferential of 5°C) is reached, then unit
goes back to its original state.
02 +2°C
03 +3°C
04 +4°C
05
+5°C
06 +6°C
07 +7°C
08 +8°C
09 +9°C
