ESIE15-11A | Part 3. Field settings 5. Wired remote controller BRC1E52
23/09/16 Page 39
VRV4 indoor units
1c 0 display of actual room temperature 01 off
02
on
1 selection air thermistor shown in room
temp display (for auto mode and set-
back function only)
01 air return (R1T) For auto-function & setback
02
thermistor of BRC1E
2 Visualisation of mode display on
remocon in auto mode
01 off Whether or not 'heating/cooling’ is dis-
played during automatic mode (other-
wise only 'automatic' is mentioned on
remocon)
02
on
3 disable level 01
level 2 (low, high; on/off;
operation mode)
02 level 3 (on/off)
4 backlight on 01 permanently off
02
on for 30 seconds when
pushing any button
03 always on
5 operation when backlight is off 01
no when pushing a button, first backlight
is activated, function of button is not
activated
02 yes when pushing a button, backlight is
activated and immediately function of
button is activated
6 display of remocon 01
permanent display the screen always shows values
02 screen goes blank after 5
minutes
touching any button will reactivate the
screen
9 Sensor selection if 2 remocon 01
main controller temperature sensor of main controller
is used for ambient (in case 1c-1-2)
02 2nd controller temperature sensor of 2nd controller
is used for ambient (in case 1c-1-2)
10 Offset master remocon sensor 01 -3°C to modify displayed temperature on
remocon 1
02 -2,5°C
03 -2°C
04 -1,5°C
05 -1°C
06 -0,5°C
07
0°C
08 +0,5°C
09 +1°C
11 Offset slave remocon sensor 01 -3°C to modify displayed temperature on
remocon 2
02 -2,5°C
03 -2°C
04 -1,5°C
05 -1°C
06 -0,5°C
07
0°C
08 +0,5°C
09 +1°C
