ESIE15-11A | Part 3. Field settings 6. General indoor units
Page 44 23/09/16
VRV4 indoor units
13 /
23
0 Airflow amount setting (Ceiling height) 01 normal ceiling (<2,7m) Depends on indoor unit
02 slightly higher ceiling
(2,7m)
03 high ceiling (3m)
1 selection of airflow direction (set when
a blocking path kit has been installed,
4-way blow panel)
01
4 way directions Note: freeze-up protection will come
in when the temperature, measured
by R2T is below -1°C for 10 minutes.
02 3 way directions Note: freeze-up protection will come
in when the temperature, measured
by R2T is below 0°C for 1 minute or
below 1°C for 15 minutes.
03 2 way directions
2 Swing pattern setting if 4 swing
motors
01
all directions simultane-
ously swing
02 --
03 opposite sides synchroni-
zation swing
3 Output to flap motor 01
enabled
02 disabled
03 --
4 Setting of airflow direction adjustment
range
01 draft prevention high position (10-40°)
02
standard standard position (10-65°)
03 ceiling soiling prevention low position (30-65°)
5 fanspeed setting 01
Standard for FXFQ-M, FXHQ-M & FXZQ-M
02 Low
03 Low
Setting the static pressure selection 01
Standard (10/15Pa) for FXDQ-A & FXNQ-A
02 High static pressure
(30/44Pa)
03 Medium static pressure
04 Medium static pressure
6 External static pressure settings 01 30 Pa only for FXMQ 40 PVE
02 50 Pa for FXSQ-P/A, FXMQ-P, FXTQ-A
ESP value based on nominal airflow
rate = Hhspeed
03 60 Pa
04 70 Pa
05 80 Pa
06 90 Pa
07
100 Pa
08 110 Pa
09 120 Pa
10 130 Pa
11 140 Pa
12 150 Pa
13 160 Pa
14 180 Pa only for FXMQ 50 - 125 PVE
15 200 Pa
7 Thermostat swing 01 equipped
02 not equipped
