Operation manual
7
LRYEQ16A7Y1 + LCBKQ3AV1(E)
CONVENI-PACK
4P448940-1A – 2016.07
• The fan may keep on running for about 1 minute
after the heating operation stops for removing
the heat in the indoor unit.
• The air flow rate may be adjusted automatically
depending on the room temperature or the fan
may stop immediately. This is not a malfunction.
• For machine protection the system may control
the air flow rate automatically.
• It may take sometime for finishing to change the
air flow rate.
This is normal operation.
ADJUSTMENT (Refer to Fig.2)
For adjustment the desired temperature, fan
speed and air flow direction (only for the
remote controller: FXC, FXF, FXH), follow the
procedure shown below.
Press the temperature setting button and set
the desired temperature.
Each time this button is pressed, the
temperature setting rises or lowers
1°C.
• Set the temperature within the operation
range.
• The temperature setting is impossible for
fan only operation.
Press the fan speed control button and select
the fan speed of your preference.
Press air flow direction adjust button.
Refer to the chapter “Adjusting the air flow
direction” for details.
STOPPING THE SYSTEM (Refer to Fig.2)
Press the on/off button once again.
The operation lamp goes off and the system
stops operation.
• Do not turn off the power immediately after
the unit stops.
• The system need at least 5 minutes for
residual operation of drain pump device.
Turning off the power immediately will
cause water leak or trouble.
EXPLANATION OF HEATING OPERATION
• For general heating operation, it may take longer
to reach the set temperature than in cooling
operation.
We recommend starting the operation which
was used before using timer operation.
• The following operation is performed in order to
prevent the heating capacity from dropping or
cold air from blowing.
Defrost operation
• In heating operation, freezing of the out-
door unit heat exchanger increases. Heat-
ing capability decreases and the system
goes into defrost operation.
• The indoor unit fan stops and the remote
controller displays “ ”.
• After maximum 10 minutes of defrost oper-
ation, the system returns to heating opera-
tion again.
Hot start
• In order to prevent cold air from blowing out
of an indoor unit at the start of heating
operation, the indoor fan is automatically
stopped. The display of the remote control-
ler shows “ ”.
• The heating capacity drops as the outside tem-
perature falls. If this happens, use another heat-
ing device together with the unit. (When using
the appliances which produce open fire together,
ventilate a room constantly.)
Do not place appliances which produce open fire
in places exposed to the air flow from the unit or
under the unit.
• It takes some time for the room to warm up from
the time the unit is started since the unit uses a
hot-air circulatory system to warm the entire
room.
• If the hot air rises to the ceiling, leaving the area
above the floor cold, we recommend using the
circulator (the indoor fan for circulating air). Con-
tact your dealer for details.
5-2 PROGRAM DRY OPERATION
• The function of this operation is to decrease the
humidity in your room with a minimum tempera-
ture decrease.
• The micro computer automatically determines
temperature and fan speed.
• The system does not go into operation if the
room temperature is low.
• The microcomputer automatically controls the
temperature and fan speed, so these cannot be
set using the remote controller.
• This function is not available if the room tem-
perature is 20°C or lower.
4PEN448940-1A.book Page 7 Thursday, August 25, 2016 11:23 AM
