Pressure Out put
(kPa G) (V)
– 500 – 1.03
– 400 – 0.72
– 300 – 0.42
– 200 – 0.11
– 100 0.19
0 0.50
100 0.81
200 1.11
300 1.42
400 1.72
500 2.03
600 2.34
700 2.64
800 2.95
900 3.25
1000 3.56
7-4
7.6 Temperature sensor characteristics table (DCHS)
Temperature(
°C)
Temperature(
°F)
Resistance(kΩ) Temperature(
°C)
Temperature(
°F)
Resistance(kΩ)
72 162 32.783 102 216 12.566
74 165 30.629 104 219 11.835
76 169 28.635 106 223 11.153
78 172 26.787 108 226 10.515
80 176 25.073 110 230 9.919
82 180 23.482 112 234 9.361
84 183 22.005 114 237 8.840
86 187 20.633 116 241 8.351
88 190 19.358 118 244 7.894
90 194 18.171 120 248 7.465
92 198 17.066 122 252 7.063
94 201 16.037 124 255 6.685
96 205 15.078 126 258 6.331
98 208 14.184 128 262 5.998
100 212 13.350 130 266 5.686
7.7 High pressure transducer
characteristics table
Pressure Out put Pressure Out put
(kPa G) (V) (kPa G) (V)
0 0.50 1100 1.62
100 0.60 1200 1.72
200 0.70 1300 1.83
300 0.81 1400 1.93
400 0.91 1500 2.03
500 1.01 1600 2.13
600 1.11 1700 2.23
700 1.21 1800 2.34
800 1.32 1900 2.44
900 1.42 2000 2.54
1000 1.52 2100 2.64
7.8 Low pressure transducer
characteristics table
