Daikin MC401VE Service Manual

Parts List SiE74-202
42 Reference Data
2.2 Parts List
MC401VE
No.
Index
Parts No. Parts Name Drwg. No. Parts Model Specification Q’ty/Unit Wiring
Symbol
Notes
MC401VE
C1 1127201 SIROCCO FAN ASS’Y 3P040480-2 1
C2 A 1119541 PRE-FILTER 3P040468-1 1
C3 A 1119565 AIR FILTER 3P037627-1 1
C4 A 1119572 AIR FILTER 3P037627-2 1
C6 A 1204038 ROLL FILTER ASS’Y 4P056567-2 1
E1 A 1204184 PRINTED CIRCUIT BOARD
(DISPLAY)
2P057722-1 EH0004 1 A2P
E2 1127218 WIRE HARNESS (FOR DISPLAY) 4P041558-1 1
E3 1127225 CASING, ROLL FILTER 1P040619-1 1
E4 1083301 OPERATION PLATE 4P031138-1 1
E5 A 1127249 ELECTRODE PLATE 3P041555-1 1
E6 1127256 IONIZER WIRE SET FRAME 1P040616-1 1
E7 A 1126479 IONIZER WIRE ASS’Y 4P042943-1 2
E8 B 1127263 SPRING (GROUND WIRE) 4P041556-1 1
E9 B 1127270 SET PLATE, IONIZER WIRE 3P041721-1 1
E10 A 1101603 PRINT CIRCUIT (HIGH
VOLTAGE)
3P041572-1 ECXC3018 1 A4P
E11 A 1194559 PRINTED CIRCUIT (CONTROL) 2P057721-1 EH0003 1 A1P
E11-1 A 0509002 FUSE 3EB82010-1 3.15A 250V
D5.2XL20
1 F1U
E12 A 1187359 PRINT CIRCUIT BOARD
(INVERTER)
3P058359-1 EH0011 1 A3P
E13 1127287 WIRE HARNESS (SAFETY
SWITCH)
4P041606-1 1
E13-1 B 0944357 SWITCH 4P008757-1 1 DS1
E15 A 0948809 HIGH VOLTAGE CONTACT ASS’Y 4P010108-1 1
E15-1 1021257 HIGH VOLTAGE CONTACT FRAME 3P009404-1 1
E15-2 0948816 HIGH VOLTAGE CONTACT 4P010467-1 1
E16 A 0948816 HIGH VOLTAGE CONTACT 4P010467-1 1
E17 B 1204045 LAMP ASS’Y 3P064207-1 1
E18 A 1194566 FAN MOTOR 3P063028-1 KFD-280-17-8A 8P 17W 280V 1M1F
E19 1127294 WIRE HARNESS (FOR FAN
MOTOR)
4P041605-1 1
E21 1188794 WIRE HARNESS (FOR HVU) 4P059255-1 1
E22 1127326 WIRE HARNESS (INVERTER) 4P041607-1 1
E23 1214352 POWER CORD 3P060210-1 1
F1 1119510 FRONT PLATE 1P040502-1 1
F2 1127333 CONTROL DISPLAY COVER
(FRONT)
1P040421-1 1
F3 1127340 CONTROL DISPLAY COVER
(REAR)
1P040459-1 1
F4 1204052 REAR PLATE 1P058586-1 1
F5 1214369 CASING FRAME (MIDDLE) 1P058669-1 1
F6 1119558 DISCHARGE GRILLE 2P040347-1 1
F7 1127357 LEAD WIRE SUPPORT 3P040466-1 1
F8 0948203 MOTOR MOUNTING PLATE 3P006693-1 1
F9 1214376 SET PLATE 1P058499-1 1
F10 1214383 DISPLAY NAME PLATE 1P063105-1 1
F15 BOLTS AND NUTS LIST 3P064658-1 1
K1 A 1194573 WIRELESS REMOTE
CONTROLLER
3P026240-6 ARC17A53 1
K2 OPERATION MANUAL 3P026236-21 1
K3 1114003 BATTERY PACK 4PH14023-2 1
