Daikin MC707VM-S - Page 38

Photocatalytic Air Purifiers 37
SiBE81-623A Removal Procedure
Procedure Points
4. Removing the Bio-
Antibody Filter
* When assembling, catch
the bottom hooks.
(Unless the hooks are
caught, the pre-filter,
which uses the same
hooks, cannot be
assembled.)
(1) Bend the fixing part
slightly to undo upper
two hooks.
Hooks
Bio-Antibody Filter
Hooks
