Daikin MicroTech I Operating Manual

55/77
Operation Manual
D–EOMWC00A07-16_02EN
10.8.13 EEXV Comm Failure #
This alarm is generated in case of communication problems with the EEXVx module.
Symptom
Cause
Solution
Circuit status is Off.
All circuits are stopped immediately.
Bell icon is moving on controller’s
display. String in the alarm list: Cx
OffEXVCtrlrComFail String in the
alarm log:
Cx OffEXVCtrlrComFail
String in the alarm snapshot
Cx OffEXVCtrlrComFail
Module has no power supply
Check the power supply from the
connector on the side of the module.
Check if LEDs are both green.
Check if the connector on the side is
tightly inserted in the module.
Module address is not properly set
Check if module’s address is correct
referring to the wiring diagram.
Module is broken
Check if LED are on and both green.
If BSP LED is solid red replace the
module.
Check if power supply is ok but LEDs
are both off. In this case replace the
module.
Reset
Notes
Local HMI
Network
Auto



10.8.14 Evaporator Pressure Sensor Fault
This alarm indicates that the evaporating pressure transducer is not operating properly.
Symptom
Cause
Solution
Circuit status is Off.
The circuit is stopped.
Bell icon is moving on controller’s
display.
String in the alarm list:
CxCmp1 EvapPressSen
String in the alarm log:
CxCmp1 EvapPressSen
String in the alarm snapshot
CxCmp1 EvapPressSen
Sensor is broken.
Check for sensor integrity. Check
correct sensors operation according
information about mVolt (mV) range
related to pressure values in kPa.
Sensor is shorted.
Check if sensor is shorted with a
resistance measurement.
Sensor is not properly connected
(open).
Check for correct installation of the
sensor on refrigerant circuit pipe. The
transducer must be able to sense the
pressure through the valve’s needle.
Check for absence of water or
humidity on sensor electrical
contacts.
Check for correct plug-in of the
electrical connectors.
Check for correct sensors wiring also
according electrical scheme.
Reset
Notes
Local HMI
Network
Auto



