Daikin MicroTech I Installation And Maintenance

IM 1285-4 • MICROTECH III 28 www.DaikinApplied.com

Figure 28 continued: Code Update SIL
Page 6 of 9
UNIT CONFIGURATION











1
Unit Type

1=Self-Contained (SCU)
2=Commercial Rooftop (MPS)
3=Rebel Cool Only (DPS/DAH)
4=Rebel Heat Pump (DPS_H)
●
●
●
●
●
2
Control Type
0=Zone Control


●
●
●
●
●
3
Cooling Type
0 = None


2=Chilled Water
3=F&BP
4=Variable Comp Circuit 1
5=Variable Comp Circuit 2
6=VRV
7=NA
8=NA
9=Digital Comp 1 Circuit
10=Digital Comp 2 Circuits
●
●
●
●
●
4
Compressorized
Cooling
Configuration
0=None
1=Generic Condenser
2=2Cmp/2Circ/3Stg
3=3Cmp/2Circ/4StgorVar
(Var used for initial MPS026,
030&035 release)
4=2Cmp/2Circ/2or6StgorVar
(6 stg if 7=2,3,4or5)
5=3Cmp/3Circ/3Stg_NoWRV
6=3Cmp/3Circ/3Stg_WRV
7=4Cmp/2Circ/4StgorVar
8=4Cmp/4Circ/4Stg_NoWRV
9=4Cmp/4Circ/4Stg_WRV
A=6Cmp/2Circ/6StgorVar
B=6Cmp/6Circ/6Stg_NoWRV
C=6Cmp/6Circ/6Stg_WRV
D=3Cmp/2Circ/5StgorVar
E=4Cmp/2Circ/5or8StgorVar
(Var used for initial MPS040)
(8 stg if 7=2,3,4or5
)
F=8Cmp/4Circ/8Stg
G=8Cmp/8Circ/8Stg
H=6Cmp/3Circ/6Stg
I=Not Used
J=3 Cmp/3Circ/4Stg
K=Spare
L=1Var/1Circ
M=Var/1STD/1Circ
●
●
●
●
●
5
Generic Condenser
Stages
1 – 8 Stages ()/
●
●
(if
4=4,
5or
6)
●
(if
4=4,
5or
6)
6
Low Ambient
0
1 = Yes
This position
currently has no
effect on unit
operation.
7
Condenser Control
0=Std Method 1
1=Std Method 2
2=Evap ABB
3=Evap MD2
●
●
●
●
